GE IC5KS182SSP Solid State Circuit Breaker Module
GE IC5KS182SSP
GE IC5KS182SSP is a high-performance solid-state power protector or solid-state circuit breaker module manufactured by the Industrial Solutions Division of General Electric (GE). This module belongs to GE’s Innovation Series control products and is designed to provide fast and reliable overcurrent and short-circuit protection for industrial equipment and control systems. GE IC5KS182SSP uses solid-state semiconductor technology to replace traditional mechanical circuit breakers or contactors, enabling microsecond-level (μs) fault response speed—far exceeding the millisecond-level speed of electromechanical components. Its core value lies in providing the highest level of circuit protection for sensitive electronic equipment, motor drives, power buses, or entire control panels. Through almost instantaneous fault current limitation, it effectively prevents equipment damage, reduces arc flash risks, and minimizes production downtime. It is an advanced solution for enhancing electrical safety and availability in critical industrial applications.
Product Parameters
- Product Model: IC5KS182SSP
- Manufacturer: GE (General Electric)
- Product Type: Solid-state circuit protector / Solid-state circuit breaker
- Rated Voltage: 480 VAC (or determined by the model suffix)
- Rated Current: 182 Amps (indicated by “182″ in the model)
- Pole Count: 3-Pole
- Interrupting Technology: Solid-state semiconductor (e.g., SCR / Thyristor)
- Response Time: Microsecond-level (μs)
- Control Power Supply: 24 VDC (typical value, for internal logic and triggering)
- Status Indication: LED indicators (power, status, fault)
- Communication Interface: May support hardwired alarm signals or optional communication modules
- Mounting Method: DIN rail mounting or panel mounting
- Certifications: cULus, CE
Structure and Composition
The GE IC5KS182SSP module features a robust industrial-grade metal housing, which provides excellent heat dissipation and electromagnetic shielding performance. The front of the module is equipped with high-visibility LED indicators to display operating status, ready status, and any fault conditions. The incoming and outgoing lines of the three-phase power supply are connected via large screw terminal blocks on the top or bottom of the module; these terminals are designed to carry high currents.
Its internal core consists of a three-phase solid-state switch array (usually composed of anti-parallel thyristor pairs), a high-speed current sensing circuit (e.g., Hall effect sensor), a control logic board, and a gate drive circuit. The control logic board continuously monitors the load current; when an overcurrent or short circuit is detected, it immediately sends a signal to the gate drive circuit, thereby turning off the solid-state switch extremely quickly. The module may also include an independent low-voltage DC power interface to supply power to the internal electronic circuits.
Key Features and Advantages
- Ultra-High-Speed Protection: The core advantage of the module is its microsecond-level fault response speed. This significantly limits the energy let through (I²t) at the fault point, effectively protecting expensive downstream equipment (such as frequency converters, servo drives, and PLCs) from damage—an capability that traditional circuit breakers or fuses cannot match.
- Enhanced Arc Flash Protection: Due to its extremely fast breaking speed, it significantly reduces the arc flash energy and duration that may occur during a short-circuit event. This provides higher safety for maintenance personnel near the equipment and helps comply with workplace safety regulations.
- Long Lifespan and Maintenance-Free Operation: Solid-state technology has no moving mechanical parts, so it does not wear out due to arc erosion (unlike mechanical circuit breakers) nor suffers from contact aging caused by frequent operations. This achieves truly maintenance-free operation and an extremely long service life.
- Precise Current Protection: Electronic current detection and protection logic allow for very precise and adjustable overcurrent protection settings. It provides more accurate protection characteristics than thermal-magnetic trip units, avoiding unnecessary false tripping while ensuring reliable operation when real faults occur.
Application Fields
The GE IC5KS182SSP module is specifically designed for industrial applications that require the highest level of power protection and high availability. It is commonly used to protect critical production equipment, such as large PLC control cabinets, DCS system enclosures, robot controllers, and servo drive groups.
In high-value, high-downtime-cost environments (e.g., semiconductor manufacturing, data center power distribution units (PDUs), glass manufacturing, and automotive production lines), it is used to protect sensitive loads from grid-side or load-side faults. It is also suitable for scenarios that require high arc flash safety levels.
Installation and Maintenance
Pre-Installation Preparation
Before installing the GE IC5KS182SSP module, a qualified electrical engineer must conduct system design to ensure its ratings perfectly match the protected circuit. Installation must be performed only after the system is completely de-energized, verified as de-energized, and locked out/tagged out (LOTO). Confirm that the installation location has sufficient space for heat dissipation and wiring. Use a torque screwdriver to fasten the power terminals according to the torque value specified by the manufacturer.
Maintenance Recommendations
Daily maintenance mainly involves keeping the module clean and ensuring good ventilation for heat dissipation. Regularly check whether the status indicators are normal. The module itself is maintenance-free.
If a trip or fault indication occurs, first investigate whether there is a short circuit or overload in the downstream load. After the fault cause is completely eliminated, the module must be reset by cycling the control power supply. It is recommended to regularly use dedicated test equipment to verify the normal operation of its protection functions.
————————————————————————————————————-
