GE IC694ALG392 Analog Output Module
GE IC694ALG392
Overview
IC694ALG392 is an 8-channel analog output module designed to convert digital signals from a PLC (Programmable Logic Controller) into analog signals, which are used to control external devices or systems. This module supports both voltage and current outputs, featuring high precision and high resolution. It is well-suited for applications in the industrial automation control field.
Parameters
- Module Type: Analog Output Module
- Number of Channels: 8 single-ended output channels
- Output Range:Resolution: 15 bits (current mode) or 16 bits (voltage mode)
- Voltage: 0 V to +10 V, -10 V to +10 V
- Current: 0 mA to 20 mA, 4 mA to 20 mA
- Update Rate: 12 milliseconds per channel
- Output Impedance: < 1 Ω
- Power Supply Voltage: 24 V DC
- Power Consumption: 2 W
Product Features
- High Precision and High Resolution: Supports multiple input types, including voltage, current, thermocouple, and RTD (Resistance Temperature Detector), enabling it to meet diverse application requirements.
- Ease of Use: Facilitates easy installation, configuration, and operation, and is compatible with the GE Fanuc 90-30 PLC series.
- High Reliability: Equipped with LED indicators that display the module status and external power supply conditions.
Certifications
The module has obtained certifications such as UL, UL HAZLOC, Zone 2 CE, and ATEX C1D2.
Structure and Composition
- Module Structure: The module is equipped with 8 output channels, and each channel can be independently configured for voltage or current output.
- Installation Method: Can be installed in any I/O slot of the RX3i system and supports DIN rail installation.
- Power Supply: Requires an external 24 V DC power supply, and can also obtain 5 V DC power through the PLC backplane.
Application Fields
- Industrial Automation: Widely applied in the field of industrial automation, covering industries such as manufacturing, petrochemicals, energy, water treatment, and food and beverage.
- Specific Applications: Used for controlling actuators (e.g., motors, valves), process control, data transmission, and test systems.
Installation and Maintenance
- Installation: The module can be installed in any I/O slot of the RX3i system and supports DIN rail installation.
- Configuration: Can be configured via programming software such as Logicmaster 90-30/20/Micro or CIMPLICITY Control, allowing users to select parameters like output range and address.
- Maintenance: Features LED indicators for monitoring the module status and power supply conditions.
————————————————————————————————————-
