GE IS200EBACG1A AC Feedback Board

Short Description:

The GE IS200EBACG1A is an Exciter Bridge AC Feedback Board belonging to the GE EX2100e series excitation control system. As one of the core components of the excitation control system

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: GE

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-15359273791

( WhatsApp )Wechat: + 86-15359273791

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

GE IS200EBACG1A

1. Overview

The GE IS200EBACG1A is an Exciter Bridge AC Feedback Board belonging to the GE EX2100e series excitation control system. As one of the core components of the excitation control system, it is specially designed for industrial power generation applications and undertakes key signal feedback and system coordination functions in the excitation control process.

2. Product Features

Digital Control Function: Serving as a digital controller for thyristor-based systems, this board is compatible with thyristor systems of 42mm, 53mm, 77mm and 100mm specifications, delivering stable and accurate digital control performance.

Power Conversion Function: In the EX2100e system, the board acts as a core functional unit matching the inverter Silicon Controlled Rectifier (SCR) and the full-wave three-phase Power Conversion Module (PCM), realizing efficient power conversion and regulation.

System Communication Capability: It supports connection with High-Speed Serial Link (HSSL) communication devices and Exciter Auxiliary (EAUX) boards, enabling high-speed data transmission and stable signal interaction within the system.

Advanced Technology: The EX2100e series incorporates cutting-edge digital control technology, and the suffix “e” represents its upgraded enhanced technical performance compared with traditional series products.

High System Reliability: Equipped with redundant control capabilities, it can provide effective backup operation when individual system components fail, ensuring uninterrupted and stable operation of the entire excitation system.

3. Structure and Composition

At present, the complete physical parameter information of the board (including dimensions, weight, pin definition, etc.) has not been fully disclosed. The confirmed structural and attribute information is as follows:

Functional Type: AC feedback board, categorized under the EACF product series

System Installation Position: Installed inside the equipment auxiliary cabinet

Connection Mode: Cooperates with the Exciter Backplane (EBKP) and serves as an intermediate control unit for signal interaction and function coordination between the two boards

Note: For detailed technical specifications such as operating voltage, physical dimensions, weight and connector type, please refer to GE official manuals GEH-6632 and GEI-100465.

4. Application Fields

Synchronous Generator Excitation Control: Implements precise excitation control, real-time status protection and high-precision parameter measurement for synchronous generators to guarantee stable power output of generators.

Turbine Monitoring and Control: Widely applied in the operational control of gas turbines and steam turbines. It can monitor and regulate core operating parameters including vibration, pressure and temperature to ensure safe and efficient turbine operation.

Industrial Process Monitoring: Suitable for chemical, petrochemical, energy production and other industrial scenarios that require high-precision control of mechanical systems, supporting stable operation of complex industrial production processes.

Power Generation System: Adaptable to multiple power generation scenarios, including steam power generation (nuclear power generation included), gas power generation and hydropower generation, covering mainstream industrial power generation fields.

5. Installation and Maintenance

5.1 Official Installation Manuals

Main Manual: GEH-6632 EX2100 Excitation Controller User’s Guide

Supplementary Document: GEI-100465 Exciter AC Feedback Board Manual (for EX2100 series systems)

5.2 Installation Precautions

Before installation, verify that the on-site installation environment meets the standard operating temperature and humidity requirements of the equipment.
Thoroughly clean the interior of the power conversion cabinet to eliminate dust and foreign matter that may affect equipment operation.
Inspect all connecting interfaces and lines to ensure no damage, aging or poor contact.
Confirm that the on-site power supply parameters are fully compatible with the board’s operating specifications.
Connect all circuits in strict accordance with the official installation procedures to ensure firm and correct wiring connections.

————————————————————————————————————-
