GE IS200EDISG1A Power Allocation Board

Short Description:

The GE IS200EDISG1A is an Exciter Power Distribution Board designed for the EX2100e thyristor digital control system. It serves as a core component of the GE Speedtronic Mark VI and Mark VIe series, and is fully compatible with the EX2100e product lineup.

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: GE

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-15359273791

( WhatsApp )Wechat: + 86-15359273791

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

GE IS200EDISG1A

1. Product Overview

This module is primarily responsible for connecting customer AC or DC control power supplies to the control system hardware, and it supports 125VDC power input from multiple power sources to ensure stable power supply for system operation.

2. Technical Specifications

Parameter Item	Specification
Model	IS200EDISG1A
Manufacturer	General Electric (GE)
Origin	United States
Product Type	Exciter Power Distribution Board
DC Input Voltage	125VDC
AC Input Voltage	115/220VAC (50/60Hz)
Rated Current	5A
Rated Voltage	220V
Resistance	5 Ohms
Auxiliary Power Voltage	28VDC
Output Current	10A (Partial reference data)
Operating Temperature	-20°C to 100°C / -20°C to 65°C (Minor differences in different reference materials)
Storage Temperature	-40°C to 85°C
Dimensions	302 x 22mm / 19.00 x 12.50 x 3.5 inches
Weight	2.90 lbs
Communication Protocol	HSSL, Modbus TCP/IP, Ethernet Modbus
Ingress Protection Rating	IP65 (Partial reference data)

3. Product Features

High Reliability: As a critical component of the EX2100e excitation control platform, it delivers stable and high-performance operation, ensuring overall system reliability for industrial control scenarios.
High-Speed Communication: It connects I/O boards and various functional modules to the main control processor board of the EX2100e system via High-Speed Serial Link (HSSL), realizing fast data transmission and signal interaction.
Redundancy Support: Compatible with single, dual and triple redundancy modes, effectively reducing system failure risks and significantly improving system availability and operational stability.
Plug-and-Play Design: Adopts a pluggable terminal board connection structure, which simplifies on-site installation, daily inspection and equipment maintenance, reducing operation and maintenance costs.
Compact Structure: Features a miniaturized and compact structural design, which occupies less space and can be easily integrated into existing industrial control systems with strong compatibility.
Rich Interfaces: Equipped with 11 switches and 52 female connectors on the board, supporting diversified wiring and multi-device connection to meet complex system connection requirements.
Intelligent Functions: Integrates intelligent operation monitoring, fault alarm, data transmission, real-time display and manual operation functions, realizing intelligent and visualized system management.

4. Structure and Composition

4.1 Core Component

The core structure of the product is a high-precision power distribution printed circuit board (PCB), which undertakes core functions such as power distribution, signal transmission and equipment connection.

4.2 System Integration

This module is a standard matching part of GE Speedtronic Mark VI and Mark VIe series systems, and is widely integrated into the thyristor-based digital control system EX2100e, serving as an important power distribution and signal connection unit of the system.

4.3 Power Supply Mode

The board supports multiple power supply modes. It can receive 125VDC power input from station batteries, and also adapts to dual-channel 115/220VAC 50/60Hz AC power input. The AC power is rectified by the DACA board to supply stable power for controllers, bridge interface boards and I/O boards of the whole system.

4.4 Communication Connection

It establishes high-speed data connection with the main processor card through HSSL. Meanwhile, it supports standalone and redundant application of auxiliary functions, ensuring coordinated and efficient operation of each functional unit of the system.

4.5 Product Number Description

The model number contains multiple attribute information, including EDIS functional code, Mark VI series grouping standard, PCB coating type and Class A revision version, which can accurately reflect product functions, series attributes and technical versions.

5. Application Fields

5.1 Power Plant Excitation Control System

New construction and renovation projects of steam turbine generators
New construction and renovation projects of gas turbine generators
New construction and renovation projects of hydroelectric generators

5.2 Turbine Automation System

Gas turbine automatic drive control system
Steam turbine automatic drive control system
Wind turbine automatic drive control system

5.3 Industrial Fields

Industrial automation and control systems
Petroleum and natural gas industry
Manufacturing industry
Water treatment industry
Electric power, steel, cement, shipbuilding, papermaking and other heavy industrial industries

————————————————————————————————————-
