GE IS220PDOAH1BC IS230SNRLH2A IS200SRLYH2AAA Discrete Output Packet Module

Short Description:

The IS220PDOAH1BC is a Discrete Output Pack Module belonging to the GE Speedtronic Mark VIe series, categorized as a digital output module.

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: GE

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-15359273791

( WhatsApp )Wechat: + 86-15359273791

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

GE IS220PDOAH1BC IS230SNRLH2A IS200SRLYH2AAA

1. Overview and Parameters of IS220PDOAH1BC

1.1 Overview

The IS220PDOAH1BC is a Discrete Output Pack Module belonging to the GE Speedtronic Mark VIe series, categorized as a digital output module. It is a variant model of the IS220PDOAH1B series, primarily deployed to execute digital output control tasks for various on-site field devices.

1.2 Product Features

Specially optimized for output tasks, perfectly applicable to systems requiring dedicated output functions
Supports redundant configuration to effectively enhance overall system reliability
Equipped with high-precision output signal performance
Modular structure design enables convenient and fast installation
Supports dual 100Mbps full-duplex Ethernet port communication

1.3 Technical Parameters

Parameter Item	Specification
Operating Temperature	-20°C to +60°C
Rated Voltage	24.0 VDC, maximum rating 28.6 VDC
Number of Relay Channels	12 channels
Power Requirement	24V DC
UL Certification	Applicable to non-hazardous and hazardous locations

1.4 Structure and Composition

Multi-layer PCB board design
Adopts SMD surface-mount components
Equipped with standard connector interfaces

1.5 Application Fields

Power Plants: Used for the control of steam turbines, boilers and other core equipment
Petrochemical Industry: Applied to control on-site equipment such as valves and pumps
Process control systems
Mechanical automation application scenarios

2. Overview and Parameters of IS230SNRLH2A

2.1 Overview

The IS230SNRLH2A is an 8-channel Discrete Output Relay Module, exclusively designed for GE Mark VIe and Mark VIeS control systems. This module provides high-voltage relay output signals to drive on-site actuators including solenoid valves and contactors.

2.2 Product Features

Integrates 8 independent discrete relay output channels
Supports high-voltage relay output to meet industrial heavy-load control demands
Enables distributed I/O functions for Mark VIe / VIeS platform systems
Supports simplex, duplex and triplex redundant configuration modes

2.3 Technical Parameters

Parameter Item	Specification
Model	IS230SNRLH2A
Module Type	Discrete Output Relay Module
System Compatibility	Mark VIe / Mark VIeS
Number of Output Channels	8 discrete relay outputs
Origin	United States

2.4 Structure and Composition

Multi-layer PCB board structure
Full SMD surface-mount component layout
Equipped with detachable terminal block connectors
Supports standard DIN rail mounting

2.5 Application Fields

Gas turbine control systems
Steam turbine control systems
Power generation facilities
Industrial automated process control
Scenarios requiring precise output control

3. Overview and Parameters of IS200SRLYH2AAA

3.1 Overview

The IS200SRLYH2AAA is a terminal board of the Mark VIe series, used for connection and signal interaction with external I/O devices. Correlated with the IS230SRLYH2A (either a renamed version or a matching accessory of the same product series), it is a digital output DIN rail mounted module.

3.2 Product Features

Compact and streamlined shape design for easy system integration and installation
Fully compliant with relevant industry standards and specifications
Built-in LED indicator lights for real-time operating status monitoring
Integrated solid-state circuit breaker and soft-start function for equipment protection
Supports on-line maintenance and automatic system reconfiguration functions

3.3 Technical Parameters

Parameter Item	Specification
Dimensions	16cm × 16cm × 12cm
Weight	0.8kg
Operating Voltage	28V DC
Power Input Requirement	24V DC input voltage
Communication Interface	Dual 100Mbps full-duplex Ethernet ports
Origin	United States

3.4 Structure and Composition

High-performance multi-layer PCB circuit board
Precision SMD surface-mount electronic components
Detachable terminal block connectors for convenient wiring
Built-in LED status indicator lights

3.5 Application Fields

Supporting use with GE Fanuc PLC systems
General industrial automation systems
Industrial data acquisition systems
Machine tool control systems
Gas turbine control systems (used as gas turbine control cards)

4. System Compatibility Description

All three products are compatible with the GE Speedtronic Mark VIe / VIeS control system platform. This upgraded platform inherits and expands the functions of the traditional Mark VI architecture, with core optimized capabilities as follows:

Powerful distributed I/O processing capability
Diversified and expanded communication options
Closer integration with factory-level monitoring and control systems

The hardware product series covers IS200 and IS220 series boards, fully covering industrial I/O processing, system control and data communication functions, and can meet diverse industrial control scenario requirements.
