GE VMIVME-7588 CPU module
GE VMIVME-7588
1. Product Overview
2. Main Parameters and Specifications
|
Item
|
Specification Details
|
|---|---|
|
Model
|
VMIVME-7588
|
|
Processor
|
Enhanced Intel Pentium Processor
|
|
Memory Interface
|
Supports PC133 SDRAM expansion with single-slot SODIMM design
|
|
Storage
|
Equipped with flash memory; supports floppy disk and hard disk options (compatible with VMIVME-7452 hard disk module)
|
|
Network Interface
|
100 Mbit Ethernet Port
|
|
Communication Interface
|
RS-232 serial port, USB port, optional SCSI interface
|
|
Power Requirements
|
+5V DC, +12V DC, -12V DC (compliant with VMEbus 3.1 standard)
|
|
Operating Temperature
|
-20°C to +70°C (standard industrial grade range)
|
|
Storage Temperature
|
-40°C to +85°C
|
|
Dimensions
|
Standard VME Eurocard module size
|
|
Weight
|
Approx. 0.5 kg (standard single-slot module)
|
Part Number Variants
- 350-007588-9L7P
- 350-007588-787 K
- 332-000234-001E
- VMIVME-7588-977
- VMIVME-7588-997
3. Product Features
3.1 High-Performance Processor Architecture
- Adopts Intel Pentium processor to deliver powerful data processing capability
- Supports Advanced Transfer Cache (ATC) technology
3.2 VME Bus Compatibility
- Fully compliant with VMEbus Specification Rev. C.1
- Equipped with standard VME P1 and P2 connectors
- Supports VME64 extended standards
3.3 Rich I/O Interfaces
- Built-in SVGA display controller
- Dual serial communication ports (RS-232/RS-485)
- USB 2.0 interface
- Dual Ethernet ports (partial models)
3.4 Reliable Industrial Design
- Industrial ruggedized construction
- Compliant with EMC/EMI standards
- Capable of stable operation in harsh industrial environments
3.5 Strong Expandability
- Supports PMC/PICMG expansion slots (configuration dependent)
- Compatible and collaborative with other VMIVME series modules
4. Structure and Composition
4.1 Main Board System
- CPU Subsystem: Centered on Intel Pentium processor core
- Memory Subsystem: Equipped with SDRAM/SODIMM expansion slot
- VMEbus Interface Logic: Implements standard VME bus communication and control functions
4.2 I/O Subsystem
- SVGA/VGA video display controller
- Keyboard and mouse interface
- Network Interface Controller (NIC)
4.3 Connector Configuration
- Rear Side: P1, P2 VMEbus connectors
- Front Panel: Integrated I/O panel including Ethernet, serial, USB and other interfaces
- Optional VME64 enhanced connector support
4.4 Firmware and Operating System Support
- PC/AT compatible systems: MS-DOS, Windows 95/NT and other classic desktop operating systems
- Real-time operating systems: VxWorks, QNX, Linux and other industrial-grade RTOS
————————————————————————————————————-
