1. Overview

2. Key Specifications

• Power Supply Range: DC 9V – 36V (wide-range redundant power supply, ensuring the system operates normally in case of power supply failure)
• Communication Interfaces:

  Transmission Rate: Supports high-speed transmission of 155Mb/s

  • CAN Bus: Supports dual CAN2.0A/B buses, providing 1-2 CAN electrical ports
  • Optical Fiber Interface: Supports 1-2 155M optical fiber interfaces with a communication distance of up to 60km
• Protection Level: IP30 (suitable for industrial DIN rail mounting environments)
• Operating Temperature: -20°C to +60°C (industrial-grade temperature range)

_____________________________________________________________________________________________________________

3. Product Features

• Redundant Design: Supports dual-network redundancy (dual CAN bus and dual optical fiber). When one communication line fails, the other can take over immediately to ensure system continuity.
• High Reliability: Adopts a corrugated aluminum reinforced chassis, with lightning protection, overcurrent protection, and surge protection functions.
• Long-Distance Communication: Optical fiber ring network topology design, suitable for data transmission in large-scale industrial plants (such as petrochemical, iron and steel plants, etc.).
• Easy Maintenance: Equipped with 6 bicolor LED status indicators, facilitating quick on-site diagnosis of module status.

_____________________________________________________________________________________________________________

4. Structure and Composition

• Power Supply Unit: Responsible for receiving external power and distributing it, with wide-range redundant input.
• Communication Unit: Includes CAN bus interface and optical fiber interface, usually located on the back or side of the module.
• Indicator Light and Panel: Used to display power supply, communication, fault and other statuses.
• Mounting Structure: Adopts 35mm standard DIN rail mounting, easy to integrate into standard industrial distribution cabinets.

_____________________________________________________________________________________________________________

5. Application Fields

• Petrochemical Industry: Used in safety instrumented systems for oil refining and chemical production.
• Energy and Power: Suitable for safety control systems in power plants and generating stations.
• Iron and Steel Manufacturing: Provides safe communication in iron and steel plants with high temperature and complex process flows.
• Offshore Platforms: As optical fiber communication has a long distance, B5233 is one of the key components on offshore oil platforms.
• Other Industrial Automation: Widely used in scenarios requiring high safety integrity levels (SIL 2/SIL 3).

_____________________________________________________________________________________________________________

6. Installation and Maintenance Recommendations

Installation

• Rail Mounting: Use standard DIN rail to ensure firm fixation.
• Wiring: Connect the red wire to the positive pole of the power supply and the black wire to the negative pole; the CAN and optical fiber interfaces must be correctly connected according to the system design drawing.
• Protection: Ensure the installation environment is dry to avoid moisture intrusion (although the protection level is IP30, it is still recommended to use it in a dry environment).

Maintenance

• Regular Inspection: Check the LED indicators to confirm that the power supply and communication status are normal.
• Cleaning: Regularly clean the dust on the surface of the module to prevent overheating caused by dust accumulation.
• Connection Inspection: Check whether the optical fiber and CAN cable connections are firm to prevent poor contact caused by vibration.
