HIMA F3300 Digital Output Module
HIMA F3300
1. Overview
HIMA F3300 is a high-performance Digital Output Module manufactured by HIMA GmbH (a leading enterprise in the field of safety automation) from Germany. It is usually integrated into HIMA’s safety platforms (such as H51q, H51r) and mainly used in industrial safety-critical systems.
Famous for its safety redundancy design, precise control capability and high reliability, this module is a key hardware to ensure rapid response in high-risk industrial scenarios such as emergency shutdown, fire linkage and gas monitoring.
2. Typical Parameters
|
Parameter
|
Specification
|
|---|---|
|
Operating Voltage
|
24 V DC (DC24V)
|
|
Number of Channels
|
8 independent outputs (16 channels supported by some versions)
|
|
Output Current
|
2A per channel (NPN/PNP open collector output)
|
|
Communication Interface
|
Ethernet/IP, Modbus TCP, POC (Process Object Communication)
|
|
Operating Temperature Range
|
-40°C – +85°C
|
|
Environmental Adaptability
|
Complies with IEC 61508 SIL 3 certification, industrial-grade protection (dustproof, waterproof, anti-vibration)
|
3. Product Features
Safety Redundancy
Adopts redundant architecture and hot-swappable technology, supports parallel operation of dual CU modules, reduces the risk of single-point failure, and ensures high system availability.
Efficient Communication
Supports industrial protocols such as Ethernet/IP and Modbus TCP, enabling seamless integration with DCS/PLC systems to achieve fast data interaction and linkage.
Precise Control
Designed for precise control of actuators (such as valves, relays), widely used in critical safety scenarios such as Emergency Stop (E-Stop) and fire protection linkage.
Industrial Reliability
Complies with IEC 61508 SIL 3 certification, with resistance to harsh environments (high temperature resistance, vibration resistance, electromagnetic interference resistance).
4. Structure & Components
- Module Body: Usually 19-inch standard rack size (about 3U), fixed with DIN rail, facilitating integration with other industrial control equipment.
- Interface Terminals: Equipped with clearly marked terminal blocks, corresponding to power input, digital output channels and communication interfaces (RJ45 or dedicated ports) respectively.
- Heat Dissipation Device: Built-in heat sink or fan to ensure stable operation in harsh environments from -40°C to +85°C.
5. Application Areas
- Oil & Gas: Safety interlock, emergency shutdown, gas leakage monitoring.
- Chemical & Pharmaceutical: Process monitoring, key process parameter monitoring, clean room safety control.
- Power Generation & Electricity: Unit protection, valve control, relay protection.
- Metallurgy & Steel: High-temperature furnace safety monitoring, conveyor system interlock.
- General Industrial Automation: As an I/O execution module in DCS/PLC systems, controlling external equipment (such as relays, actuators).
6. Installation & Maintenance
Installation Points
- Cabinet Fixing: Fix the module in a DIN rail cabinet that meets IEC 60204‑1 standard, ensuring good grounding of the cabinet.
- Power Connection: When connecting 24 V DC power supply, be sure to check the polarity and use cables that meet the specifications to prevent power fluctuations from damaging the module.
- Communication Wiring: Connect the module to the HIMA safety controller through the corresponding industrial bus (such as Ethernet/IP, PROFIBUS), ensuring that the communication cables meet the shielding requirements.
Maintenance Recommendations
- Regular Inspection: Regularly clean the surface of the module, check the contact condition of the terminal blocks to ensure no corrosion or looseness.
- Power Supply Monitoring: Regularly monitor the supply voltage of the module to ensure it is within the rated range, preventing module failure caused by overvoltage or undervoltage.
- Firmware Upgrade: Pay attention to the firmware upgrades released by HIMA official, and update in time to obtain better compatibility and security.
————————————————————————————————————-
