1. Product Overview

2. Main Parameters & Specifications

3. Product Features

• Safe and Reliable: Complies with IEC 61508 SIL 3 standard, ensuring safe communication in high-risk environments.
• Compact Design: Flat cable structure design, suitable for cabinets or equipment interiors with limited space.
• High Compatibility: Can connect various input/output modules in HIMA system (such as I/O bus connection module F7553).
• Durability: Made of high-quality materials, with anti-interference and wear-resistant capabilities, adapting to harsh industrial environments.

4. Structure & Composition

• Connector: One end is usually connected to the I/O subrack or equipment, and the other end is connected to the main rack or computer system. The connector is usually of M12 type to ensure firm insertion and water resistance.
• Wire Core: It contains multiple individually shielded or twisted wire cores, each responsible for transmitting different digital or analog signals.

5. Application Fields

• Industrial Automation Control Systems: Used to connect PLC, DCS (Distributed Control System) with safety modules.
• Process Control Systems: Used to connect process control sensors (such as temperature and pressure sensors) and actuators.
• Energy & Power Systems: Used to connect DCS monitoring systems of power plants, intelligent fire water supply control systems, etc.
• Transportation: Used in railway signal systems, traffic signal control systems, etc.

6. Installation & Maintenance Recommendations

• Connection Check: During installation, ensure that the M12 connector is aligned and inserted all the way to avoid signal interruption caused by poor connection.
• Avoid Over-Bending: Although the flat cable is soft, over-bending should still be avoided to prevent damage to internal wires.
• Regular Inspection: Regularly check whether the cable surface is worn, aged or cut, and ensure the quality of signal transmission.
