HIMA F6214 Analog Input Module
HIMA F6214
The HIMA F6214 is a 4-channel analog input module designed for functional safety (SIL 3) systems, specifically engineered to collect safety-related signals in industrial process automation. It supports 2-wire (4…20 mA) and voltage (0…1 V, 0…5 V, 0…10 V) inputs, enabling safe isolation and high-precision acquisition of sensor signals such as pressure, flow, and temperature.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Number of Channels | 4 channels |
| Input Type | 4…20 mA (2-wire); Voltage (0…1 V, 0…5 V, 0…10 V) |
| Resolution | 12 bit |
| Accuracy | ±0.1% of Full Scale (FS) |
| Power Supply | 24 V DC |
| Safety Level | SIL 3 (compliant with IEC 61508) |
| Communication Interface | Standard HIMA Bus (X-SB / X-DO) |
| Ambient Temperature | -25 °C ~ +55 °C |
| Protection Rating | IP20 (DIN Rail Mounting) |
Product Features
- High Safety: Built-in safety isolation meets SIL 3 requirements, preventing the propagation of faulty signals.
- Fast Response: Short signal acquisition response time ensures real-time performance.
- Easy Integration: Adopts standard HIMA bus interface and DIN rail structure, compatible with existing HIMA Safety Instrumented Systems (SIS).
- Multiple Input Ranges: Supports current and multi-voltage ranges to adapt to different sensors.
- High Resolution & Accuracy: 12-bit resolution and ±0.1% full-scale accuracy meet strict measurement requirements.
- Reliability: Uses industrial-grade components to resist vibration and shock, suitable for harsh on-site environments.
Structure & Composition
- Module Body: Compact DIN rail-mounted housing with 4 independent analog input channels inside.
- Power Sub-module: 24 V DC power supply with overvoltage and overcurrent protection.
- Communication Sub-module: Enables bus communication (X-SB / X-DO) with HIMA master stations.
- Safety Isolation Unit: Each channel is equipped with an independent safety isolation circuit to prevent fault propagation.
- Indicator Lights: LED status indicators for quick on-site diagnosis.
Typical Application Fields
- Process Industry: Safety Instrumented Systems (SIS) in chemical, petroleum, natural gas, and pharmaceutical industries.
- Power Systems: Safety monitoring and control in power plants and substations.
- Steel, Cement, and Automotive Manufacturing: Safety signal acquisition for high-risk processes.
- Other Automation Systems Requiring Functional Safety: Safety-related control in industries such as textiles and energy.
Installation & Maintenance Guidelines
Installation
- Fix the module on a DIN rail, ensuring horizontal installation to avoid mechanical impact.
- Follow the wiring diagram in the module manual during wiring, and distinguish between current and voltage input terminals.
- Confirm the power supply voltage is 24 V DC, and ensure the power supply line is equipped with necessary filtering and protection.
Commissioning
- Use HIMA’s supporting configuration software to set channel parameters (input range, calibration coefficient).
- Check the module status and signal integrity through the bus monitoring function.
Routine Maintenance
- Regularly inspect terminal connections, indicator lights, and heat dissipation to prevent loosening or corrosion.
- Perform a functional self-test at least once a year to verify that the safety isolation performance complies with specifications.
- If abnormal signals or indicator alarms are detected, replace the faulty channel or the entire module promptly, and contact the manufacturer’s after-sales service.
————————————————————————————————————-
