HIMA F8652E Processor Module
HIMA F8652E
1. Product Overview
- Type: HIMA F8652E Safety Controller CPU Module (HIMA Module)
- Applicable Industries: Process control, manufacturing, power, petrochemical, natural gas, and other automated systems requiring SIL 3 safety integrity level
- Certification: Complies with SIL 3 safety standards and features a Fail-Safe design
2. Key Technical Specifications
| Parameter | Specification |
|---|---|
| Operating Voltage | 24 V DC (±15%) |
| Output Voltage | 0-10 V DC |
| Maximum Output Current | 500 mA |
| Operating Temperature | -20 °C ~ 60 °C (marked as -40 °C ~ 70 °C in some documents) |
| Storage | 256 KB SRAM (for safety logic) + 2 MB FLASH (for programs) |
| Processor | 32-bit RISC, with a main frequency of ≥200 MHz, supporting double-precision floating-point |
| Communication Interfaces | Ethernet, Serial Port, Modbus TCP/IP, HIMax Safety Bus |
| Protection Class | IP20 (dust-proof) |
| Dimensions | 120 mm × 80 mm × 40 mm (or 163 mm × 38 mm × 58 mm, depending on the specific model) |
| Weight | Approximately 0.4 kg ~ 1.6 kg |
| Warranty Period | 2 years |
3. Product Features
- High Safety: Complies with SIL 3 and adopts a Fail-Safe design, suitable for critical safety functions.
- Multi-Protocol Compatibility: Supports industrial communication protocols such as Ethernet, Modbus TCP/IP, and HIMax, facilitating system integration.
- Strong Anti-Interference: Features an industrial-grade protection design (IP20) and a wide operating temperature range, adapting to harsh on-site environments.
- Modular Structure: Supports standard DIN rail mounting, enabling quick replacement or expansion in the cabinet.
- Low Power Consumption: Typical power consumption ≤ 5 W, reducing system energy consumption.
4. Structure and Composition
- CPU Core Board: Equipped with a 32-bit RISC processor, responsible for safety logic operations.
- Storage Unit: Includes safety SRAM and FLASH for program and safety data storage.
- Power Supply Module (e.g., F7130A): Provides a 24 V DC regulated power supply.
- Communication Interface Board: Supports Ethernet, serial port, Modbus TCP/IP, HIMax Bus, etc.
- I/O Interfaces: Features analog output (0-10 V) and digital input/output terminals.
- Protective Enclosure: Made of metal or high-strength plastic, meeting IP20 protection class requirements.
5. Application Fields
- Process Safety Systems (SIS): Valve safety control, Emergency Shutdown (ESD) systems.
- Industrial Automation: Collaborative control of PLCs and safety PLCs.
- Power Systems: Safety monitoring and protection for power generation, transmission, and distribution.
- Petrochemical & Natural Gas: High-risk processes such as leak detection and explosion protection.
- Manufacturing: Robot safety, assembly line protection.
6. Installation and Maintenance Guidelines
| Step | Key Points |
|---|---|
| 1. Pre-Installation Check | Verify that the power supply (24 V DC) and grounding meet specifications; check the size of the cabinet DIN rail. |
| 2. Mechanical Installation | Slide the module onto the DIN rail and secure it with screws; ensure the module is level and stable. |
| 3. Wiring | Connect the power supply, analog I/O, digital I/O, and communication ports according to the wiring diagram; use protective junction boxes to prevent loosening. |
| 4. Software Configuration | Use HIMA’s supporting engineering software (e.g., HIMA-Safe) for safety function programming, parameter setting, and SIL assessment. |
| 5. Functional Testing | Perform a self-test after power-on; verify the normal operation of I/O response, communication connectivity, and safety functions (Fail-Safe). |
| 6. Operation Monitoring | Real-time monitor the module status, temperature, power consumption, etc., via HMI or SCADA; set alarm thresholds. |
| 7. Regular Maintenance | Check the tightness of wiring and heat dissipation every 6-12 months; remove dust; update firmware or safety programs (must comply with SIL change management procedures). |
| 8. Troubleshooting | If a fault indicator light is on or a self-test error occurs, refer to the fault code manual for troubleshooting; replace the power supply or I/O module if necessary. |
————————————————————————————————————-
