HIMA Z7138/3330/C5/P2 Control Module
HIMA Z7138/3330/C5/P2
1. Overview
It is a safety control module belonging to the HIMA Z7138/3330/C5/P2 HIMA Blackhorse series, which complies with the IEC 61508/61511 standard and supports the SIL 3 safety level.Adopting a 19-inch 4U rack-mounted structure, it supports DIN rail installation and features a fanless heat dissipation design, making it suitable for high-reliability and harsh industrial environments.
2. Key Parameters
- Model: Z7138/3330/C5/P2
- Rack Size: 19 inches × 4U
- Power Supply: 24 V DC (main power supply) + 5 V DC (auxiliary power supply)
- Communication Interfaces: Modbus RTU, RS‑232/RS‑485, Ethernet (optional)
- Protection Level: IP20 (inside the rack)
- Operating Temperature: –25 °C ~ +55 °C
- Safety Level: SIL 3 (compliant with IEC 61508)
- Compatibility: Interchangeable with same-series modules such as HIMA Z7136, Z7116, and Z7127
3. Product Features
- High Reliability: Adopts a redundant dual-card design and supports hot-swap replacement to ensure uninterrupted system operation.
- Modular Structure: Can flexibly combine sub-modules such as I/O, communication, monitoring, and power supply, facilitating system expansion.
- Fanless Heat Dissipation: Reduces maintenance costs and extends service life.
- Safety Certification: Complies with IEC 61508/61511 and has passed SIL 3 certification.
- Multiple Communication Options: Built-in multiple fieldbus and Ethernet interfaces, compatible with various upper-level systems.
4. Structure and Composition
Central Rack
- Central Unit (CU)
- Communication Module (CM)
- Power Supply Module (24 V DC/5 V DC)
- Power Monitoring Module (F7131)
I/O Rack (Optional)
- Power Distribution Module
- Up to 16 channels of digital/analog I/O sub-modules
Redundant Cards
Two sets of cards with the same function are installed in the upper and lower card cages respectively to realize parallel redundant operation.
5. Application Fields
- Petroleum, Chemical, and Natural Gas Industry: Safety control for hazardous processes.
- Power, Iron and Steel, and Cement Industry: Safety monitoring of large-scale continuous production lines.
- Pharmaceutical, Automotive, and Textile Industry: High-reliability automation systems.
- Energy and Environmental Protection Industry: Safety layer of Distributed Control Systems (DCS).
6. Installation and Maintenance
- Installation: Fix it on the DIN rail in accordance with the product manual, ensure that the cards are inserted in place, and avoid impact and vibration.
- Wiring: Follow the IEC 61850/61508 wiring specifications, and use shielded cables to connect the power supply, I/O, and communication ports.
- Commissioning: Use the configuration software provided by HIMA for parameter setting and function testing.
- Maintenance: Regularly check the power supply status, card temperature, and connection tightness; in case of failure, redundant cards can be replaced by hot-swap without shutting down the system, reducing downtime.
————————————————————————————————————-
