Main Technical Parameters

• Product Model: F3331
• Input Voltage: 24 V DC (common configuration)
• Output Channels: Multiple channels (the specific number of channels depends on the specific sub-model)
• Operating Temperature Range: –20 °C ~ +60 °C
• Relative Humidity: 5% ~ 95% (non-condensing)
• Protection Level: IP20 (for indoor use)
• Safety Certifications: EN 61508 SIL 3, EN 62061, IEC 61511
• Dimensions (W × H × D): 180 mm × 270 mm × 94 mm
• Weight: Approximately 1.5 kg
• Communication Interfaces: Ethernet, Modbus, TCP
• Warranty Period: 1 year

Product Features

1. Highly Reliable Power Supply: Adopts a redundant power supply design to ensure that critical equipment can still work normally in the event of a power failure.
2. Safety Protection: Built-in multiple protection functions such as overcurrent, overvoltage, and overheating, complying with the SIL 3 safety standard.
3. Real-Time Monitoring: Capable of monitoring power quality (voltage, current, temperature) and reporting status through communication interfaces.
4. Modular Structure: Features a compact DIN-rail installation size, facilitating quick arrangement and replacement in the cabinet.
5. Multi-Protocol Compatibility: Supports industrial communication protocols such as Ethernet, Modbus, and TCP, enabling easy integration with upper-level systems.
6. Environmental Adaptability: With a wide operating temperature range and strong moisture resistance, it is suitable for harsh environments such as workshops and factories.

Structure and Composition

• Power Input Unit: Responsible for receiving external power, filtering, and voltage stabilization.
• Redundant Power Supply Module: Implements dual-channel power supply or hot backup to improve system availability.
• Output Driver Board: Provides multiple controlled outputs and is equipped with overcurrent/overvoltage protection circuits.
• Monitoring and Diagnostic Chip: Collects parameters such as voltage, current, and temperature in real time and generates fault diagnosis information.
• Communication Interface Board: Enables network connections such as Ethernet and Modbus.
• Cabinet Mounting Bracket: Complies with the DIN-rail standard for quick assembly.

Typical Application Fields

• Process Automation: Safety power supply for continuous production processes in chemical, petroleum, natural gas, and other industries.
• Mechanical Manufacturing: Power supply guarantee for high-precision equipment such as CNC machine tools and robots.
• Energy Systems: Power supply for key control units in power plants and distribution networks.
• Transportation: Safety power supply for rail transit and aviation ground equipment.
• Building Automation: Power supply for fire protection and security systems in large buildings.

Installation and Maintenance Points

1. Pre-Installation Inspection: Confirm that the cabinet space, DIN-rail specifications, and input voltage meet the product requirements.
2. Wiring Specifications: Follow the IEC 60204-1 standard, use cables that meet specifications, and ensure the terminal blocks are securely fastened.
3. Ventilation and Heat Dissipation: The module generates heat during operation, so sufficient ventilation or forced heat dissipation in the cabinet must be ensured.
4. First Power-On Test: After power-on, use the diagnostic software provided by HIMA to check whether the status of each channel and protection functions are normal.
5. Regular Maintenance: Every 6 to 12 months, check the tightness of the wiring, the corrosion of terminals, and the operation status of cooling fans (if any).
6. Fault Diagnosis: Use the built-in monitoring and communication functions to remotely read fault logs and quickly locate abnormalities.
