1. Product Overview

2. Main Parameters and Specifications

3. Product Features and Advantages

• TMR Redundancy Architecture Support: Compatible with single-unit and Triple Modular Redundancy (TMR) architectural designs, effectively improving system operational stability and fault tolerance.
• Hot-Swap Function: Supports online hot swapping, enabling equipment maintenance and replacement without interrupting the normal operation of the entire control system.
• Automatic Reconfiguration: Allows convenient replacement of I/O boards without manual system reconfiguration, simplifying operation and maintenance processes.
• Plug-and-Play Performance: Automatically identifies connected power distribution modules via built-in electronic IDs, realizing quick docking and deployment.
• High-Precision Measurement: Accurately measures and feeds back key parameters of the power distribution system, including voltage, current and frequency, ensuring accurate system data monitoring.
• Industrial-Grade Reliability: Adopts high-quality industrial-grade electronic components, which can maintain stable and reliable operation in complex and harsh industrial environments.

4. Structure and Composition

5. Application Fields

• Power Plants: Control system of gas turbines and steam turbines
• Oil and Gas Facilities: Operational control of oil and gas transmission and delivery systems
• Industrial Process Control: Automated production and process monitoring in manufacturing industries
• Water Treatment Industry: Stable power guarantee and power system monitoring for water treatment equipment
• Metallurgy and Chemical Industry: Real-time monitoring of production environments under high temperature and high pressure conditions
• Data Centers: Precision monitoring and safety guarantee of core power supply systems
• Microgrid Systems: Power parameter monitoring and system control for renewable energy power generation equipment

6. Installation and Maintenance

6.1 Installation Requirements

• Operating Ambient Temperature: 0°C to 55°C
• Relative Humidity: Less than 85% (non-condensing environment)
• Heat Dissipation Space: Do not install the module under high-heat components. Ensure sufficient ventilation and heat dissipation space around the equipment to avoid heat accumulation affecting operation.
• Vibration Protection: Keep away from strong vibration sources to avoid continuous vibration with a frequency of 10-55Hz. If vibration interference is unavoidable, install damping accessories such as damping rubber for vibration reduction protection.

6.2 Maintenance Precautions

• Hot-Swap Operation: The module supports live-line hot swapping. Static electricity protection measures must be implemented during operation to avoid static damage to electronic components.
• Reconfiguration Restrictions: System restart is prohibited during automatic system reconfiguration, and all other data download tasks need to be completed in advance or postponed until the reconfiguration is finished.
• Fault Diagnosis Function: Built-in self-diagnosis test module, which can automatically detect ground faults and fuse status anomalies to facilitate rapid fault location and troubleshooting.
• Document Reference: Read the official product manual and safety operation guidelines carefully before installation and use to ensure standardized operation and equipment safety.
