1. Product Overview

2. Main Technical Parameters

3. Interfaces and Communication

• Ethernet Interface: 2 industrial Ethernet ports, supporting high-speed data exchange and remote monitoring and management
• Serial Interface: RS232/RS485 interface
• Bus Interface: CAN bus interface
• Display Screen: Integrated diagnostic display function for convenient status monitoring and fault diagnosis

4. Structure and Composition

• Base Module: I/O expansion modules such as TB5610-2ETH
• Power Supply Module: Series power supplies including PS5611-MC
• Communication Module: Communication expansion modules such as CM579-ETHCAT
• Digital I/O Module: DI561 (8DI), DI562 (16DI), DO561 (8DO), DO562 (16DO) and other models
• Analog I/O Module: AI561, AI562, AO561, AX561 and other models

5. Product Features

• High-Performance Processing: Ultra-fast processing speed of 0.00001ms, fully applicable to high-precision real-time control scenarios
• Diversified Communication Capabilities: Equipped with dual Ethernet ports, RS232/RS485 interface and CAN bus interface to meet the communication requirements of complex industrial networks
• Integrated Diagnostic Display: Simplifies on-site equipment maintenance and rapid fault troubleshooting
• Industrial-Grade Reliability: Designed with a wide operating temperature range (-20°C to +60°C), adapting to harsh industrial operating environments
• Strong Expandability: Compatible with a full range of AC500 series I/O modules and communication expansion modules for flexible system upgrade
• USB Software Update: Supports program upgrading and system maintenance via USB interface, reducing operation difficulty

6. Application Fields

• Factory Automation: Production line control and industrial process control
• Water Treatment Industry: Pump station control and water supply system monitoring (e.g., Rīgas ūdens project)
• Remote Monitoring System: Distributed industrial data acquisition and systematic management
• Energy Management: Control and real-time monitoring of power systems
• Smart Manufacturing: Various application scenarios oriented to Industry 4.0

7. Installation and Maintenance

7.1 Key Installation Steps

• Assembly Preparation: Inspect the processor module and base module to confirm no damage or defects
• Installation and Fixation: Secure the processor module on the base module with screws
• Wiring Connection: Complete the wiring of Ethernet ports, serial interfaces, power supply and other terminals
• Grounding Protection: Ensure reliable grounding connection to guarantee operational safety
• Space Requirement: Reserve installation space matching the module size of 62mm×76mm×67.5mm

7.2 Key Maintenance Guidelines

• Regular Cleaning: Remove dust on the module surface regularly to avoid affecting heat dissipation and operation
• Routine Inspection: Periodically check the tightness of wiring connections and the status of indicator lights
• Software Upgrade: Update system programs via USB interface to optimize equipment performance
• Environmental Management: Keep the operating temperature within the standard range of -20°C to +60°C

7.3 Warranty and Return Policy

• Standard Warranty Period: 1 year
• Return Policy: Returns are acceptable within 30 days upon purchase. The product must be unused, unopened and kept with complete original packaging.

8. Product Configuration Recommendation
