ProSoft MVI56-AFC Interface Module
ProSoft MVI56-AFC
Overview
The ProSoft MVI56-AFC (Flow with Battery Backed RAM) is a high-performance interface module specifically engineered for Allen-Bradley ControlLogix PLC platforms. Primarily designed for the measurement and control of industrial gas flow, this module integrates with high-precision flowmeters to enable real-time monitoring and management of gas flow processes. Equipped with battery-backed RAM functionality, it ensures the retention of critical data even during power outages.
Core Specifications
- Model Number: MVI56-AFC / 1.03
- Input Voltage: 24V DC (industrial standard voltage)
- Power Consumption: Maximum 3.5W
- Operating Temperature Range: -40°C to +70°C (suitable for harsh industrial environments)
- Battery Backup: Built-in battery supports RAM data retention, ensuring data integrity after power failure
- Interface Type: Compatible with 1756 ControlLogix backplane, featuring single-slot design
- Communication Interfaces: Supports RS232/RS485/RS422 serial communication
- Storage Capacity: Supports up to 10,000 16-bit register mappings, with CF card slot for hot-swappable configuration backup
Key Features
- High Reliability: Industrial-grade design ensures stable long-term operation, withstanding environmental challenges such as vibration and temperature fluctuations.
- Battery-Backed Data Protection: The integrated battery safeguards critical configuration and metering data stored in RAM against power loss.
- Flexible Programming Capabilities: Users can configure parameters and program logic via ProSoft Configuration Builder software, adapting to diverse flow measurement requirements.
- Multi-Protocol Compatibility: Supports Modbus, DF1 and other industrial communication protocols, facilitating seamless integration with third-party sensors and devices.
- Advanced Data Management: With 10,000 register mappings and flexible data storage, configuration backup via CF card simplifies on-site debugging and module replacement.
Structure and Components
- Main Control Unit: Embedded microprocessor and battery backup system, responsible for flow measurement calculations and data storage.
- Communication Ports: Provides RS232, RS485 and RS422 ports to support serial communication.
- Power Interface: 24V DC power supply with integrated battery backup circuit.
- Mounting Interface: 1756 backplane slot design, compatible with local or remote rack installation.
- Storage Medium: CF card slot enables hot-swappable backup of configuration files.
Application Areas
- Industrial Gas Metering: Ideal for gas flow measurement in petrochemical, natural gas processing and chemical production facilities.
- Process Control: Applied in manufacturing process automation, such as monitoring the opening degree of flow control valves.
- Energy Management: Monitors gas consumption and transmission volume at energy stations (e.g., gas supply stations).
- Laboratory Automation: Enables precise control and recording of gas flow in experimental processes.
Installation and Maintenance Recommendations
Installation Preparation
- Perform installation only after disconnecting system power to prevent electrostatic damage to the module.
- Inspect backplane slots and module interfaces for dust or foreign objects before installation.
Wiring Requirements
- Ensure correct connection of RS232/RS485/RS422 cables; avoid parallel routing with high-voltage wires to minimize electromagnetic interference.
Configuration Steps
- Hardware Installation: Insert the module into the corresponding slot of the 1756 backplane and ensure the locking clip is securely fastened.
- Software Configuration: Use ProSoft Configuration Builder within RSLogix 5000 to set parameters such as flowmeter type and baud rate.
- Data Mapping: Map measured values to tags or registers in the PLC program.
- Download and Verification: Download the configuration to the module and check LED indicator status to confirm normal communication.
Routine Maintenance
- Regularly inspect wiring terminals and clean the module surface.
- Periodically check battery level and replace the battery when necessary.
- Back up configuration files stored on the CF card to enable rapid system recovery in case of faults.
————————————————————————————————————-
