PROSOFT MVI56-DFCM

1. Overview

2. Key Specifications

• Communication Protocol: Supports Allen‑Bradley DF1 protocol (half‑duplex / full‑duplex), compatible with Allen‑Bradley SLC 500, MicroLogix, and ControlLogix platforms.
• Operating Modes: Configurable as Master or Slave, supporting both half‑duplex and full‑duplex communication.
• Interface Type: Provides RS232 serial communication port.
• Power Requirements: Typically uses 24V DC power, compliant with ControlLogix backplane standards.
• Dimensions: Standard 1756 backplane module size, suitable for rack or field installation.
• Memory: Configurable user‑defined register mapping for data exchange.

3. Product Features

• Standardized Design: Complies with Rockwell Automation module specifications, ensuring seamless integration with ControlLogix systems.
• Flexible Communication Modes: Supports multiple DF1 communication modes and can switch between half‑duplex and full‑duplex to adapt to different network topologies.
• Easy Configuration: Configured via ProSoft Configuration Studio and Rockwell Automation’s Studio 5000 (RSLogix 5000), with module status directly viewable in PLC tags.
• Diagnostic Capabilities: Equipped with LED indicators and software diagnostics for monitoring communication status and quick troubleshooting.
• Multi‑language Support: Manuals and software support multiple languages for global users.

4. Structure and Components

• Serial Communication Interface (RS232/RS485/RS422): For connecting field devices.
• Controller Tags: Communication objects defined in the PLC program.
• Configuration Software: ProSoft Configuration Studio for setting communication parameters.
• Diagnostics and Indicators: LED indicators on the module front panel show communication status.

5. Application Areas

• Industrial Automation: Connects Allen‑Bradley PLCs with various field I/O devices such as sensors and actuators.
• Process Control: Transmits process data in manufacturing, chemical, oil, and other process control systems.
• Data Acquisition: Enables data exchange between PLCs and PCs or HMIs.
• Fieldbus Networks: Used for upgrading legacy systems requiring reliable master/slave serial communication.

6. Installation and Maintenance

• Installation: The module complies with ControlLogix backplane specifications and is inserted directly into the controller slot. Ensure power is turned off during installation and follow the module’s orientation markings.
• Configuration: Communication parameters are set using ProSoft Configuration Studio, and tags and objects are defined in Studio 5000.
• Maintenance: LED indicators provide status monitoring. Common maintenance includes checking cable connections, monitoring communication error counts, and performing remote diagnostics via software.
