PROSOFT MVI69-PDPS Communication Module
PROSOFT MVI69-PDPS
Product Overview
The ProSoft MVI69-PDPS is a communication module designed for industrial automation systems. Its core function is to convert Allen-Bradley PLC systems into slave devices within a Profibus DP network, enabling PLCs to read from or write data to field devices via the Profibus network.
Specifications
- Communication Protocols: Profibus DP, Profibus DPV1
- PLC Platform Compatibility: Rockwell Automation CompactLogix (1769) and MicroLogix (1768) platforms
- I/O Capacity: Supports cyclic transmission of 200 Words of I/O data
- Power Supply & ConsumptionPhysical Dimensions: Standard 1769 single-slot module size
- Power Consumption: Maximum 0.75 W
- Backplane Current: 800 mA (80 W)
- Supply Voltage: 48 VDC (powered via backplane)
- Certification: Equipped with PROFIBUS PNO certification (issued by Profibus & Profinet International, Germany)
Key Features
- Cross-platform Compatibility: Compatible with RSLogix 5000 (ControlLogix) and RSLogix 500 (MicroLogix) platforms
- Flexible Data Exchange: Supports data transmission via Ladder Logic
- High-speed Communication: Complies with Profibus DPV1 protocol, with Non-cyclic Message (NRT) and Non-cyclic Read/Write (NRT) capabilities
- Field-friendly Design: Integrated with LED status indicators and supports backplane diagnostics
- Configuration Storage: Communication configuration data can be stored in the module’s internal memory
Structure & Components
- Configuration Port: Used for parameter configuration of the module via PC software (e.g., RSLogix 5000)
- LED Indicators: Display module status, power status, port activity and other key information
- Physical Interfaces: Equipped with a 2.5mm M12 connector (for connecting to Profibus DP bus) and a standard 1769 backplane slot
Application Areas
- Industrial Automation Control: Such as packaging machinery, production line automation and other scenarios
- Process Control Systems: Systems requiring communication with process control instruments (e.g., transmitters, control valves)
- Field Device Integration: Integrating Rockwell PLCs with field devices from other brands (e.g., Siemens, Schneider Profibus devices)
Installation & Maintenance
Installation
- Insert the MVI69-PDPS into an empty slot of the Allen-Bradley 1769 backplane (i.e., the rack of CompactLogix or MicroLogix systems)
- Connect to the Profibus DP master station via the 2.5mm M12 interface (usually a DP master module of PLC or other DP master devices)
Configuration
- Set parameters such as node address, communication rate and I/O size via RSLogix 5000 software
- Download the configured parameters to the module after completion
Maintenance
- Regularly check the LED status indicators to monitor the communication health
- In case of communication errors, inspect the network cable connections and node address configuration
- The module supports hot-swapping, allowing replacement during system operation under normal circumstances
————————————————————————————————————-
