PROSOFT PLX82-EIP-PNC Power Input Module
PROSOFT PLX82-EIP-PNC
1. Product Overview
The PLX82-EIP-PNC is a dedicated gateway from ProSoft Technology’s ProLinx series. It acts as a “protocol translator” between an EtherNet/IP Server and a PROFINET Controller, enabling seamless communication between these two major industrial protocols.
Core Function:Converts I/O data between EtherNet/IP controllers (such as Rockwell Automation PLCs) and PROFINET controllers, allowing bidirectional data exchange.
Typical Applications:Solving interoperability issues between devices from different manufacturers, enabling cross-platform data sharing and control.
2. Technical Specifications
- Processor: Intel XScale PXA255
- Memory: 64 MB (including 64 MB NAND FLASH)
- Storage: 64 MB NAND FLASH, plus CompactFlash card support
- Communication Interfaces: 2 x 10/100 Mbit Ethernet (RJ45)
- Max PROFINET Devices: Up to 36 (including I/O modules, drives, HMIs, etc.)
- I/O Data Capacity: 3840 bytes input / 3840 bytes output
- Minimum RPI: 2 ms
- Power Supply: 24 VDC (10–36 VDC compatible), 400 mA (max 610 mA)
- Dimensions: 5.52 x 2.06 x 4.37 inches (14.01 x 5.24 x 11.09 cm)
- Operating Temperature: 0°C to 50°C
- Storage Temperature: -10°C to 70°C
- Certifications: UL, CB, PROFINET, ODVA EtherNet/IP compliant
3. Key Features
- Multi-Protocol Support: Bridges EtherNet/IP and PROFINET for cross-vendor integration.
- High Performance: 2 ms minimum RPI for real-time control applications.
- Flexible Configuration: Configured via ProSoft Configuration Builder (Windows-based) with graphical interface and remote diagnostics.
- Large I/O Capacity: Up to 3840 bytes input/output for large-scale data transfer.
- Remote Maintenance: Remote configuration, firmware upgrades, and troubleshooting via Ethernet.
- Reliable & Secure: Industrial-grade design with support for 100% network redundancy (when used with ProLinx G2 series).
4. Structure and Components
Hardware
- CPU Module: Intel XScale processor for protocol conversion and data processing.
- Power Supply: Integrated wide-voltage power module.
- Ethernet Ports: Two RJ45 ports for connecting EtherNet/IP and PROFINET networks.
Software
- ProSoft Configuration Builder: Graphical tool for gateway configuration.
- ProSoft FDT Configuration Manager: For remote maintenance and monitoring.
5. Application Areas
- Cross-vendor Automation Integration: Connect Rockwell PLCs with Siemens or other PROFINET-based controllers.
- Field Device Integration: Integrate third-party I/O, drives, and sensors into Rockwell systems.
- Process Control Systems: Link process controllers and actuators from different suppliers.
- Safety System Integration: Connect safety modules using different protocols in Safety Instrumented Systems (SIS).
6. Installation and Maintenance Guide
Installation Steps
Mount the Device
Install the unit on a DIN rail inside the control cabinet.
Connect Power
Supply 24 VDC (10–36 VDC compatible).
Connect Networks
Use the two Ethernet ports to connect the EtherNet/IP and PROFINET networks.
Configure Network Settings
Set IP address, subnet mask, and gateway via ProSoft FDT Configuration Manager or the device panel.
It is recommended to place both ports in the same subnet for easier management.
Download Firmware
Use ProSoft Configuration Builder to update firmware.Always use the latest firmware version for optimal performance.
________________________________________________
Maintenance & Diagnostics
- LED Indicators: Check power, network, and error LEDs to quickly assess device status.
- Remote Diagnostics: Use FDT Configuration Manager to view “Last Error” or “Alarm” logs.
- Firmware Upgrades: Regularly check the ProSoft website for updates and upgrade via USB or Ethernet.
- Backup Configuration: Export and save current configuration files before making major changes.
————————————————————————————————————-
