Schneider 140AVI03000 Analog Input Module
Schneider 140AVI03000
1. Overview
Schneider 140AVI03000 is a high-performance analog input module from Schneider Electric. Adopting a standard modular design, it is specifically engineered for harsh industrial environments, featuring high precision and strong anti-interference capabilities. This module is commonly used in critical process control links that require accurate measurement of voltage or current signals.
_______________________________________________________________________________________________________
2. Specifications
- Input Voltage Range: Supports ±10V voltage input (unipolar/bipolar) and ±20mA current input.
- Resolution: Uses 12-bit or 16-bit A/D converter to provide high-precision data acquisition.
- Number of Channels: The module provides 8 analog input channels, each of which can be independently configured.
- Physical Dimensions: Approximately 142mm × 126mm × 30mm (actual dimensions may vary slightly by batch).
- Operating Temperature: -40°C to +85°C, suitable for harsh industrial on-site environments.
_______________________________________________________________________________________________________
3. Product Features
- Multi-Range Configuration: Supports voltage or current input modes; input range can be configured as 0…5V, 0…10V, 4…20mA or 0…20mA.
- Anti-Interference Design: Adopts shielding design, with high impact resistance and vibration resistance, and extremely high MTBF (Mean Time Between Failures).
- Indicator Status: The module is usually equipped with indicators (about 18 pieces) for displaying communication status, error prompts and input channel status, facilitating on-site diagnosis.
- Hot Standby Function: Supports hot standby system to ensure stable operation of the system when the main module fails.
- Safety and Reliability: Complies with industrial automation standards, has electrical isolation function, and can effectively protect the control system from high-voltage impact.
_______________________________________________________________________________________________________
4. Structure and Composition
The module adopts a standard industrial rack mounting structure (usually 140 series rack), consisting of a front panel, terminal block and backplane. The front panel is equipped with connection terminals and status indicators, while the backplane provides power supply and communication interfaces (such as Ethernet/IP or Modbus).
_______________________________________________________________________________________________________
5. Application Fields
- Process Control: Suitable for monitoring process parameters such as temperature and pressure in industries such as chemical industry, oil and natural gas.
- Motion Control: Used for collecting feedback signals in servo systems.
- Power Monitoring: Monitors parameters such as motor current and voltage.
- Test and Measurement: Serves as the core component of precision measurement equipment.
_______________________________________________________________________________________________________
6. Installation and Maintenance
Installation
The module is usually installed in a Schneider standard rack, with wiring done using screw terminals. During connection, attention should be paid to the use of shielded cables and grounding treatment.
Maintenance
It has a self-test function and fault indicator lights, facilitating quick on-site fault location. It is recommended to regularly check the connection terminals and ambient temperature to ensure the module operates within the rated temperature range.
————————————————————————————————————-
