Schneider ATV310HU40N4A frequency converter
Schneider ATV310HU40N4A
1. Overview
The ATV310HU40N4A is a high-performance general-purpose inverter in Schneider Electric’s ATV310 series. As a medium and low-voltage VFD (Variable Frequency Drive) product, it is mainly used to drive low-voltage induction motors, featuring high reliability and flexible control functions. This model is typically applied to general mechanical loads, suitable for industrial equipment such as fans, pumps, and compressors.
_______________________________________________________________________________________________________
2. Key Parameters
|
Parameter
|
Description
|
|---|---|
|
Model
|
ATV310HU40N4A
|
|
Power Rating
|
4.0 kW (approximately 5.5 HP)
|
|
Rated Current
|
11.4 A
|
|
Input Voltage
|
380 – 460 VAC (Three-phase)
|
|
Output Voltage
|
380 – 460 VAC (Three-phase)
|
|
Output Frequency Range
|
0.5 Hz – 400 Hz
|
|
Cooling Method
|
Forced Cooling
|
|
Dimensions
|
Approximately 140 mm x 151 mm x 184 mm
|
|
Weight
|
1.8 kg – 1.9 kg
|
|
Suitable Motor
|
4.0 kW low-voltage three-phase motor
|
_______________________________________________________________________________________________________
3. Product Features
High-Performance Control Mode
Adopts V/F open-loop control and supports PAM (Pulse Amplitude Modulation) output, which has lower harmonic content and improves motor operation efficiency.
Easy Installation Design
Equipped with Easy Installation (EI) design, both power terminals and control terminals are marked clearly to prevent wiring errors. A wiring guide manual is attached inside the cabinet door for quick on-site installation.
_______________________________________________________________________________________________________
Rich Input/Output Interfaces
- Analog Input: Supports current or voltage input.
- Analog Output: Supports current or voltage output.
- Digital Input: 4 channels.
- Digital Output: 2 channels.
Powerful Protection Functions
It has various protection functions such as overload, short circuit, overcurrent, undervoltage, overvoltage, overheating, and insufficient cooling air volume.
User-Friendly Operation
Equipped with an integrated panel, supporting panel password protection and fault record query functions.
_______________________________________________________________________________________________________
4. Structure & Composition
- Power Components: Including IGBT power modules, rectifiers, filters, etc.
- Control Components: CPU main control board, memory, interface board, etc.
- Heat Dissipation System: Fan (forced cooling), heat sink.
- Housing & Terminal Block: Metal housing, terminal block board (Power, Control, Communication).
_______________________________________________________________________________________________________
5. Applications
- Ventilation and Air Conditioning Systems: Fan and air conditioning compressor drive.
- Water Treatment: Water pumps, sewage treatment equipment.
- Mechanical Manufacturing: Packaging machinery, printing machinery.
- Process Industry: Process loads in fields such as textiles, food, and packaging.
————————————————————————————————————-
