Schneider 140CPS11420

The 140CPS11420 is a high-performance power supply module from the Modicon series by Schneider Electric, specifically designed to deliver stable DC power to programmable logic controllers (PLCs) such as the Modicon Quantum and M340. Featuring a compact form factor and DIN rail mounting compatibility, this module is ideal for power supply and redundancy configurations in industrial automation systems.

Key Specifications

• Input Voltage: 115 V / 230 V AC (switchable), with input currents of approximately 1300 mA (115 V) and 750 mA (230 V) respectively
• Output Voltage/Current: Standard options of 5 V DC or 24 V DC, with output currents ranging from 11 A (single unit) to 20 A (parallel connection)
• Power/Efficiency: Rated at around 130 VA with efficiency >85%
• Protection Features: Overload, short-circuit, and overvoltage protection, complemented by LED status indicators
• Operating Temperature: -25 °C to +70 °C; Storage Temperature: -40 °C to +85 °C
• Dimensions/Weight: Approximately 176 mm × 89 mm × 43 mm; Weight: 0.4–0.65 kg

Product Features

• High Reliability & Long Lifespan: Built with industrial-grade components, boasting a rated mechanical lifespan of 10 million operations and electrical lifespan of 1 million operations
• Redundant Power Supply: Supports parallel connection of two modules for power redundancy, enhancing system availability
• Comprehensive Protection: Integrated overload, short-circuit, and overvoltage protection safeguards PLCs and peripheral devices
• Easy Installation: DIN rail mounting design with screw terminals, plus LED indicators for convenient on-site monitoring
• Wide Input Voltage Range: Compatible with 115 V and 230 V AC power grids, adapting to different regional electrical standards

Structure & Components

1. Power Conversion Unit: Converts AC input to regulated DC output
2. Protection Circuitry: Includes detection and disconnection mechanisms for overload, short-circuit, and overvoltage conditions
3. Indicator Lights & Status Panel: Displays operational status, faults, and other key power supply information
4. Terminals: Screw-type terminals for easy on-site wiring
5. Mounting Bracket: DIN rail structure compliant with IEC 60204 standards

Typical Application Fields

• Industrial Automation Control Systems: Powers Modicon Quantum, M340, M2 Compact PAC, and other PLC models
• Manufacturing Industry: Packaging machinery, food processing equipment, printing machines, textile machinery, etc.
• Process Control: HVAC systems, pump stations, conveyors, process instruments, etc.
• Infrastructure: Power generation, petrochemical, mining, and other scenarios requiring reliable PLC power supply

Installation & Maintenance Guidelines

Installation

• Mount on a DIN rail and ensure the module is placed horizontally
• Use screw terminals for wiring and verify connection tightness

Wiring

• Select 115 V or 230 V input interface based on the power supply, ensuring correct phase sequence
• Connect the output terminal to the PLC power bus according to system requirements

Ventilation & Heat Dissipation

• Maintain adequate ventilation around the module and avoid stacking to prevent overheating

Status Monitoring

• Real-time check the power supply status via LED indicators or PLC monitoring functions
• Immediately inspect the input power and load if a red light is illuminated or flashing

Regular Inspection

• Examine terminal connections, screw tightness, and heat sink dust accumulation every 6–12 months

Redundancy Configuration

• For high-reliability requirements, parallel two 140CPS11420 modules to ensure continuous power supply in case of a single-unit failure
