Schneider AEG MM-08MP-001 Power Distribution Module
Schneider AEG MM-08MP-001
1. Overview
2. Key Technical Parameters
| Parameter | Typical Value |
|---|---|
| Rated Voltage | 400 V / 690 V AC |
| Rated Current | 63 A (125 A, 250 A optional) |
| Rated Short-Circuit Current | 8 kA (10 kA, 15 kA, 25 kA optional) |
| Power Capacity | ≤ 45 kW (depending on module combination) |
| Operating Temperature Range | –25 °C - +55 °C |
| Protection Class | IP20 (Internal) / IP54 (Enclosure) |
| Mounting Method | Wall-mounted, frame-mounted or base-fixed (bolted or welded) |
| Module Dimensions | 300 mm (W) × 400 mm (D) × 200 mm‑800 mm (H), stackable |
| Wiring Method | Rear Busbar (MLS) or Top Busbar (MLS‑600) structure |
| Accessories | 4 × M16 side fixing bolts, 8 × M8 inter-cabinet connecting bolts |
| Certifications | IEC 61439, CE, RoHS, REACH, Green Premium™ (Environmental-friendly) |
| Warranty Period | 18 months |
3. Product Features
- Modular Design: With a unit width of 300mm, it supports horizontal or vertical stacking for quick on-site capacity expansion.
- Flexible Busbar Layout: Offers two structures (Rear Busbar MLS and Top Busbar MLS‑600) to meet diverse power distribution space requirements.
- High Short-Circuit Withstand Capacity: The maximum rated short-circuit current can reach 25 kA, ideal for high-impact industrial environments.
- Compact & Easy Maintenance: IP20 internal protection and IP54 enclosure protection, equipped with detachable side panels and quick-connect terminals for convenient maintenance.
- Environmental Compliance: Conforms to EU RoHS, REACH and Schneider Electric’s Green Premium™ environmental standards, realizing full-life-cycle recyclability.
- Versatile Mounting Options: Wall-mounted, frame-mounted or base-fixed installation adapts to equipment rooms, distribution cabinets, rail transit and other on-site scenarios.
4. Structure & Components
- Enclosure: Die-cast or stamped metal parts with IP54 protection, equipped with dustproof and waterproof seals.
- Busbar System: Copper or aluminum busbars with rear or top layout for easy electrical connection between modules.
- Terminal Block: Standard screw-type terminals supporting quick plug-in and pull-out.
- Fixings: 4 × M16 bolts (base fixing) or 8 × M8 bolts (inter-cabinet connection).
- Heat Sink: Built-in heat dissipation structure ensures stable operation in high-temperature environments.
- Distribution Unit: Optional functional modules such as circuit breakers, contactors and relays to meet different protection needs.
6. Installation & Maintenance Essentials
On-site Preparation
- Ensure the temperature of the installation location is within the range of –25 °C - +55 °C.
- Check the bearing capacity of walls or frames to meet the requirements of bolted or welded fixation.
Fixing Methods
- Wall-mounted: Fix the base to walls or brackets with 4 × M16 bolts.
- Frame-mounted: Directly weld or bolt to the distribution cabinet frame.
- Base-fixed: Reserve a gap of over 20 mm at the cabinet bottom for heat dissipation.
Electrical Connection
- Arrange busbars according to Rear Busbar or Top Busbar scheme to ensure alignment between busbar terminals and adjacent modules.
- Connect phase lines, neutral lines and protective grounding via standard screw terminals, with torque referring to IEC 61439 standard.
Inspection & Commissioning
- After wiring, use an insulation resistance tester to check insulation level (≥ 1 MΩ).
- Conduct short-circuit current pre-test before power-on to confirm that circuit breakers or protective devices operate in accordance with set values.
Daily Maintenance
- Inspect bolt tightness and terminal corrosion every 12 months.
- Clean the enclosure protective net to maintain IP54 protection performance.
- Cut off and lock the power supply before replacing internal modules, and perform plug-in and pull-out operations only when safety is ensured.
