Schneider ATV212HD45N4 frequency converter
Schneider ATV212HD45N4
Product Overview
The ATV212HD45N4 is a variable frequency drive (VFD) specifically designed for industrial applications. It features high power (45 kW / 60 hp) and high reliability, with EMC compliance and IP21 protection rating. Equipped with a high-performance built-in microprocessor, it enables precise speed and torque control, and provides rich protection functions to ensure the safe operation of equipment.
_______________________________________________________________________________________________________
Key Specifications
|
Parameter
|
Value
|
|---|---|
|
Product Model
|
ATV212HD45N4
|
|
Series
|
Altivar 212
|
|
Rated Power
|
45 kW (approx. 60 hp)
|
|
Supply Voltage
|
480 V
|
|
Phase
|
3-phase
|
|
Protection Rating
|
IP21
|
|
Electromagnetic Compatibility
|
Complies with EMC Standards
|
|
Rated Output Current
|
94 A (Continuous Output Current)
|
|
Output Frequency Range
|
0.5 – 200 Hz
|
|
Switching Frequency
|
8 kHz
|
|
Speed Range
|
1 – 10
|
|
Accuracy
|
Position Accuracy: ±10%; Torque Accuracy: ±15%
|
|
Environmental Applicability
|
Complies with RoHS, REACH and other environmental regulations; Suitable for harsh industrial environments
|
_______________________________________________________________________________________________________
Structure & Components
- Main Circuit: Includes voltage-type and current-type filter circuits, used to smooth current waveforms.
- Control Circuit: Built-in microprocessor, responsible for arithmetic and logic operations, speed detection and protection functions.
- Drive Circuit: Realizes the control of inverter power switches.
- Heat Dissipation System: Ensures heat dissipation requirements during high-load operation.
_______________________________________________________________________________________________________
Key Features
- High Power Handling Capacity: Capable of driving large motors, suitable for heavy-duty industrial equipment.
- High-Precision Control: Supports precise speed and torque control, improving system response speed.
- Rich Protection Functions: Equipped with multiple protection mechanisms such as overheating, overload and phase loss.
- Strong Environmental Adaptability: Complies with multiple international environmental regulations and has EMC compatibility.
_______________________________________________________________________________________________________
Application Fields
- HVAC Systems: Drives compressors, fans, water pumps and other equipment.
- Industrial Automation: CNC machine tools, winding, stretching, metering, yarn guiding and other equipment.
- Energy & Chemical Industry: Heavy-duty motor drives such as arc furnace feeding systems and annealing furnaces.
_______________________________________________________________________________________________________
Installation & Maintenance
Installation Notes
Ensure good ventilation of the equipment during installation and avoid being close to heating elements. If it needs to be used in a humid environment, it is recommended to use an IP54 sealed enclosure or install a filter.
Maintenance Recommendations
Regularly check if the heat sink is dusty, inspect if the electrical connections are tight, and ensure the protective cover is intact to maintain the protection rating.
————————————————————————————————————-
