Schneider ATV630D45N4 Drive
Schneider ATV630D45N4
The ATV630D45N4 is a core model in Schneider Electric’s Altivar Process series, specifically designed for harsh industrial environments. It adopts advanced Voltage Vector Control (VVC) technology, which can efficiently adjust motor speed and torque, and is widely used in precision control fields of process industry and large machinery.
_______________________________________________________________________________________________________
1. Core Technical Parameters
|
Parameter
|
Detailed Information
|
|---|---|
|
Power/Rated Power
|
45 kW (approximately 60 HP)
|
|
Voltage Level
|
380 – 480 V Three-Phase AC (220 V option compatible)
|
|
Protection Level
|
IP21 (Independent Installation), IP20 (Side-by-Side or Separate Installation)
|
|
Standard Compliance
|
Complies with IEC 61800-3 (Energy Efficiency), EN/IEC 61508 (SIL 1)
|
|
Communication Interface
|
Supports Profibus DP V1, Profinet, DeviceNet, Ethernet Port
|
|
Cooling Method
|
Plastic Enclosure Design (Fanless), Suitable for Dust Environments, Reduces Maintenance Costs
|
_______________________________________________________________________________________________________
2. Product Features & Advantages
- Green Premium: Marked as “Better World™”, the total lifecycle carbon footprint is 34,209 kg CO2 eq, compliant with RoHS Directive and mercury-free.
- Dynamic Predictive Maintenance: Built-in 3D QR code system and embedded Web server support remote monitoring and diagnosis via network, significantly reducing downtime.
- Safety: Meets Stop Category 0 of IEC/EN 60204-1 standard, with sinking/sourcing switch configuration to adapt to various logic input requirements.
_______________________________________________________________________________________________________
3. Structure & Composition
- Power Module: Responsible for efficient power conversion.
- Control Unit: Built-in CPU and DSP to process VVC algorithms.
- Human-Machine Interface (HMI): Provides settings and monitoring through LCD display.
- Communication Port Module: Supports access to various industrial networks.
_______________________________________________________________________________________________________
4. Application Fields
- Process Industry: Fluid transportation and mixing control in chemical, petroleum, and pharmaceutical industries.
- Pumps & Fans: Soft start and energy efficiency control for centrifugal pumps and axial flow fans.
- Heavy Machinery: Mining, metal processing, and large hoisting equipment.
_______________________________________________________________________________________________________
5. Installation & Maintenance Recommendations
- Installation Method: Supports independent (IP21) and side-by-side (IP20) installation. For side-by-side installation, it is recommended to set sufficient clearance (a ≥ 110 mm) to ensure heat dissipation.
- Maintenance Focus: Although it adopts a fanless design, the surface of the radiator still needs to be cleaned regularly in dusty environments to ensure heat dissipation efficiency. Using QR codes for quick fault location can greatly improve maintenance efficiency.
————————————————————————————————————-
