1. Key Specifications

2. Product Features

• High-Bandwidth Control: Adopts high-carrier-frequency PWM control, with extremely high torque output precision, capable of maintaining high efficiency under low-speed and high-torque operation.
• Powerful Communication Functions: Integrates multiple industrial communication protocols such as Modbus/TCP, CANopen, EtherNet/IP, and Profibus DP, and supports user-expanded communication cards to achieve multi-point networked control.
• Flexible I/O Configuration: Equipped with 8 discrete inputs (2 of which can be programmed as pulse inputs) and 3 analog inputs (voltage/current), which can directly connect various sensors and encoders.
• Safety & Diagnostics: Integrates safe torque off (STO) function, complying with safety standards such as IEC/EN 954-1 and EN 81-13; at the same time, it has built-in comprehensive monitoring and diagnostic tools, supporting inverter testing and oscilloscope functions.
• Energy Saving & Environmentally Friendly: Supports optional braking energy feedback function, which feeds back kinetic energy to the power grid under load fluctuation or braking conditions, significantly reducing energy consumption.

_______________________________________________________________________________________________________

3. Structure & Composition

• Power Module: Responsible for PWM output, torque control and current conversion.
• Control Unit: Built-in microprocessor, responsible for executing V/F control logic, speed feedback and advanced control algorithms.
• Communication Module: Supports different fieldbuses or Ethernet protocols according to the type of optional communication card.
• Input/Output Interface: Provides abundant terminal blocks for connecting power supplies, sensors, push buttons and actuators.
• Display & Operation Panel: Graphical operation terminal, supporting multi-language display (including Chinese).

_______________________________________________________________________________________________________

4. Application Fields

• Oil & Chemical Industry: Pump stations, compressor drives, mixer control.
• Metallurgy & Mining: Rolling mills, fans, conveyor belt control.
• Food & Beverage Industry: Filling machines, packaging machines, mixing equipment.
• Textile & Papermaking Industry: Winding machines, pulverizers, papermaking machine drives.
• Water Treatment: Water pumps, filtration systems.

_______________________________________________________________________________________________________

5. Installation & Maintenance

Installation Requirements

• Protection Level: IP21 (Protective Enclosure) / UL Type 1 (Protective Enclosure). Suitable for dry, dust-free indoor environments; if installed outside the cabinet or in a humid environment, it is recommended to use a protective cover or install it in a protective cabinet.
• Installation Clearance: For independent installation, it is recommended to keep the installation clearance a≥110mm to ensure good heat dissipation.
• Power Wiring: Supports 3-phase 380-480V power supply access. Wiring must be strictly in accordance with the wiring diagram (L1, L2, L3), and grounding must be reliable.

Maintenance & Upkeep

• Regular Inspection: Clean the dust on the heat sink every six months to ensure the fan operates normally.
• Firmware Upgrade: Check for new firmware versions through the USB port or network (Web Server) to improve functionality and security.
• Parameter Backup: It is recommended to regularly back up control parameters using SoMove software to prevent parameter loss caused by misoperation.
