Uniop ETOP12 Central Processing Unit

Short Description:

The eTOP12 is a touch display specifically designed for industrial on-site applications, mainly used to replace traditional UniOP small-size panels (such as eTOP10).

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: UniOP

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-15359273791

( WhatsApp )Wechat: + 86-15359273791

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

Uniop ETOP12

1. Overview

The eTOP12 is a touch display specifically designed for industrial on-site applications, mainly used to replace traditional UniOP small-size panels (such as eTOP10). It has undergone significant upgrades in hardware performance, primarily targeting projects that require higher resolution display, more complex user interfaces, and stronger communication capabilities.

___________________________________________________________________________________________________________________________

2. Specifications & Product Features

Specifications	Specific Values	Remarks
Display Size	5.6 Inches	Medium size, suitable for visual operations in industrial sites
Resolution	800×480 Pixels	Higher display clarity compared to old panels
Color Depth	16-bit Color (65,536 Colors)	Supports richer graphics and animations
Touch Method	Resistive Touch	Traditional industrial standard with strong oil stain resistance
Communication Interfaces	3 Ports (depending on model)	Usually includes RJ45 Ethernet, RS-485, etc.
Operating Temperature	0°C to 45°C	Suitable for common industrial environments
Protection Level	IP65 (Front Panel)	Dustproof and waterproof, suitable for harsh environments
Power Consumption	600 mA @ 24 VDC	Stable power consumption, complying with industrial standards

___________________________________________________________________________________________________________________________

3. Structure & Composition

The eTOP12 adopts a modular design, mainly composed of the following parts:

Display Unit: Includes a TFT color display and resistive touch glass.
Main Control Board: Built-in Mitsubishi JMobile Runtime environment, responsible for running HMI programs.
Front Panel: Usually made of tempered glass or high-strength plastic, equipped with status indicators.
Connection Ports: The rear panel is equipped with various communication interfaces for easy connection to PLCs or upper computers.

___________________________________________________________________________________________________________________________

4. Application Fields

Due to its improved performance, the eTOP12 is widely used in scenarios requiring high graphic display and complex operations:

Process Industry: Real-time monitoring in fields such as petroleum, chemical industry, and electric power.
Manufacturing Industry: Process control and equipment status display of production lines.
Building Automation: Human-computer interaction in large-scale facility management systems.
Equipment Maintenance: Used as a device status indicator and alarm prompt terminal.

___________________________________________________________________________________________________________________________

5. Installation & Maintenance

Installation

The eTOP12 supports wall-mounted or embedded installation. Since its protection level is IP65, attention should be paid to the front panel sealing during installation to avoid water vapor infiltration.

Maintenance

The touch screen is resistive, and its surface is relatively easy to clean, making it suitable for industrial environments that require frequent cleaning. Routine inspections include: checking for loose interfaces, cleaning the touch screen surface, and replacing aging gaskets (if any).

Note: This product is designed for industrial use only. Please follow the installation and maintenance guidelines to ensure stable operation.

————————————————————————————————————-
