UniOP eTOP30-0050

1. Product Overview

2. Technical Parameters & Specifications

• Display: 10.4-inch TFT LCD, available in resolutions of 1024×768 pixels or 640×480 pixels, ensuring clear and sharp graphical interface display for real-time operation and monitoring.
• Touch Technology: Resistive single-touch, supporting glove operation – perfectly adapted to on-site industrial working conditions.
• Communication Interfaces:

  Power Supply: 24V DC wide voltage input (18-30V DC), maximum current of approximately 1.2A, adapting to fluctuating power supply in industrial sites.

___________________________________________________________________________________________________________________________

3. Key Product Features

• Durable & Reliable: As a professional industrial HMI, it has strong anti-interference and anti-impact capabilities, maintaining stable operation even in environments with strong mechanical vibration and electromagnetic interference.
• Development-Friendly: The UniOP series adopts either CODESYS or its own proprietary development environment, featuring a simple UI, fast running speed, and convenient secondary development for equipment manufacturers.
• Multi-Protocol Compatibility: Supports a variety of industrial communication protocols (such as Ethernet/IP, Modbus, etc.), enabling easy docking with various PLCs and automation systems.

___________________________________________________________________________________________________________________________

4. Structure & Components

• Main Unit: Includes touch display, control mainboard, and base. Equipped with locking screws or mounting brackets for secure installation on machine panels.
• Backplane/Control Box: Internally integrated with power module, main control CPU, storage chips (e.g., 64MB Flash, 128MB RAM), and I/O expansion modules, supporting functional extension as needed.

___________________________________________________________________________________________________________________________

5. Application Fields

• Food Packaging Machinery
• Woodworking Machinery
• Textile Equipment
• Labeling & Filling Machinery
• Machine Tools & Special-Purpose Equipment
• Logistics Sorting Systems

___________________________________________________________________________________________________________________________

6. Installation & Maintenance

Installation

Maintenance

• Cleaning: Wipe the screen with a soft dry cloth; do not use chemical cleaners, as they may damage the surface of the resistive touch screen.
• Software Upgrade: It is recommended to use the officially recommended development environment for software updates to prevent compatibility issues.
• Power Management: Ensure the power supply voltage is within the rated range; overvoltage or overcurrent may damage internal circuits.
