Product Overview

Core Specifications

• Display Screen: 7.0-inch TFT color display, resolution 800×480 pixels (WVGA), 16:9 wide screen, LED backlight.
• Touch Technology: Resistive touch screen, supporting 5-point touch operation.
• Memory: 64 MB (for storing graphics and programs).
• Storage Expansion: USB host port (for connecting flash drives to upgrade programs and firmware).
• Communication Interface: 10/100 Ethernet port (for network communication and remote programming).
• Expansion Slot: Supports optional plug-in modules (such as TCM, SCM modules) for connection to fieldbus systems.

___________________________________________________________________________________________________________________________

Product Features

• High Industrial Stability: Designed for harsh industrial environments, with strong anti-interference ability and long service life.
• Rich PLC Communication Drivers: Supports more than 150 PLC communication protocols (such as Siemens, Mitsubishi, Omron, Allen-Bradley, etc.) with high compatibility.
• Easy Fieldbus Connection: Can easily connect to fieldbus systems through optional modules (such as TCM, SCM).
• Dual-Driver Communication Function: Supports simultaneous communication of two drivers.
• User-Friendly Software Programming: Fully compatible with UniOP Designer 6 software, featuring powerful and intuitive programming functions.

___________________________________________________________________________________________________________________________

Structure and Composition

• Ultra-Thin Design: Installation depth less than 50 mm, easy to embed in control cabinets.
• Modular Structure: The back of the host is equipped with slots for optional plug-in modules (such as TCM, SCM) for fieldbus connection.
• Housing Material: Adopts metal housing with high protection level, suitable for industrial sites.

___________________________________________________________________________________________________________________________

Typical Application Areas

• Mechanical Industry: Food packaging machinery, woodworking machinery, textile machinery, etc.
• Building Automation: Building control systems.
• Industrial Automation: Used as a host computer monitoring system to display equipment status, parameter curves, etc. in real time.

___________________________________________________________________________________________________________________________

Installation and Maintenance Recommendations

Installation Recommendations

Maintenance Recommendations

• Dust and Moisture Protection: Although it has industrial protection functions, it is still recommended to avoid strong dust and humid environments to prevent affecting touch sensitivity.
• Regular Inspection: Regularly check the connection status of USB interfaces and network interfaces to ensure stable communication.
• Firmware Upgrade: Update firmware and applications through USB interface or network connection to obtain the latest functions and security patches.

————————————————————————————————————-
