Uniop ETOP312U101

1. Product Overview

2. Core Specifications

Display Specifications

• Resolution: 800 × 480 pixels (usually 5-inch screen)
• Brightness: 300cd/m² (suitable for bright environments such as workshops)
• Contrast Ratio: 800:1

Touch Technology

• Type: Capacitive Touch (supports multi-touch)
• Features: High sensitivity, fast response speed, supports finger operation

Environmental Adaptability

• Operating Temperature: 0℃ – 50℃
• Storage Temperature: -20℃ – 60℃
• Protection Level: Generally meets IP20 (dust-proof), suitable for dry workshops

___________________________________________________________________________________________________________________________

3. Product Features

• High Reliability: The Uniop series is renowned for its industrial-grade durability, capable of adapting to high-frequency operations and long-term operation.
• Easy Integration: Supports multiple industrial communication protocols, facilitating data interaction with upper computers such as PLCs and frequency converters.
• User-Friendly Interface: Equipped with a simple and intuitive UI design, suitable for operators to get started quickly.
• Strong Durability: Impact-resistant and corrosion-resistant, suitable for use in relatively harsh industrial environments.

___________________________________________________________________________________________________________________________

4. Structure and Composition

• Display Module: Built-in high-brightness LCD display, responsible for displaying graphics and text.
• Touch Panel: Capacitive touch sensing layer that detects user operation instructions.
• Control Board: Processes display and touch data, usually with a built-in low-power ARM processor.
• Interfaces: Provides industrial standard interfaces such as RS485, RS232, USB, and CAN for data communication.
• Housing: Made of metal or high-strength plastic material to prevent physical collision.

___________________________________________________________________________________________________________________________

5. Typical Application Fields

• Packaging Machinery: Used to control packaging speed, counting, and packaging quality monitoring.
• Textile Equipment: Used to set loom parameters and monitor production progress.
• Woodworking Machinery: Operation panels for equipment such as CNC woodworking lathes and planers.
• Automation Transformation: Modernization upgrade of old equipment, equipping old machines with new interactive interfaces.
• Laboratory Equipment: Used for parameter setting and data reading of precision instruments.

___________________________________________________________________________________________________________________________

6. Installation and Maintenance

Installation Method

Maintenance Points

• Cleaning: Regularly clean the screen surface to avoid oil stains affecting touch sensitivity.
• Connection Check: Regularly check the communication interface cables to prevent signal loss caused by looseness.
• Software Upgrade: Regularly update the HMI software through USB or network interface to fix bugs or optimize interface performance.

————————————————————————————————————-
