Xycom 3715

Xycom 3715 is a compact Operator Interface (KPM) designed for industrial on-site applications. It integrates core modules including CPU, display screen, touch panel, keyboard, and power supply, serving as a direct replacement for the traditional PC + monitor combination. It supports “all-in-one, wall-mounted, or cabinet-mounted” installation. Positioned for high-reliability and strong anti-interference industrial automation environments, this series is widely used in process control, machine debugging, energy management, and other scenarios.

Key Technical Specifications

• Display Module: 15-inch TFT LCD with anti-glare treatment and a capacitive touch glass layer.
• CPU & Storage: Integrated industrial-grade processor, built-in DDR/SSD (or HDD) storage, configurable based on requirements.
• Power Supply: Internal 100-240 V AC → 24 V DC converter, rated power of approximately 150 W, supporting wide voltage range and EMI interference resistance.
• I/O Interfaces: Multiple common interfaces including USB, VGA, serial port, parallel port, keyboard, Aux, and Ethernet, meeting diverse connection needs of on-site equipment.
• Operating Environment: High temperature and humidity resistant, with IP65 protection rating, suitable for harsh industrial sites with dust and corrosive gases.
• Dimensions & Installation: Metal frame housing, offering three installation methods (wall-mounted, cabinet-mounted, or panel-mounted) for flexible on-site layout.

Product Features

• All-in-One Design: Integrates CPU, display, touch, keyboard, and power supply, eliminating external wiring and reducing system size and wiring complexity.
• Industrial-Grade Reliability: Wide voltage input, EMI interference resistance, and IP65 protection ensure long-term stable operation in high-temperature, humid, and dusty environments.
• Rich I/O Interfaces: Compatible with on-site equipment such as PLCs, DCS, and sensors, supporting multi-protocol access on-site.
• Multi-System Compatibility: Runs on Windows and Linux, enabling seamless integration with existing automation software.
• Flexible Installation: Metal frame supports wall-mounted, cabinet-mounted, or panel-mounted installation, adapting to different on-site layout requirements.

Structure & Composition (Modular Breakdown)

• Housing & Mounting Base: Metal frame providing structural support and protection.
• Display Module: 15-inch TFT LCD + anti-glare touch glass layer.
• Industrial PC Motherboard: Integrates CPU, memory, storage, and PCI/PCI-X expansion slots.
• Power Module: Internal AC → DC converter with a rated power of approximately 150 W.
• I/O Interface Panel: Features USB, VGA, serial port, parallel port, keyboard, Aux, Ethernet, etc.
• Heat Dissipation System: Fan or passive heat sink to maintain thermal balance during long-term operation.

Typical Application Areas

• Industrial Automation Control Stations: Cooperates with XYCOM HMI/PC chassis to realize on-site parameter setting and fault diagnosis.
• Manufacturing Production Lines: Machine debugging, process parameter input, and real-time monitoring.
• Heavy Industries (Energy, Petrochemical, Metallurgy, etc.): Provides reliable human-machine interaction in high-temperature, humid, or dusty environments.
• Logistics & Warehousing Systems: Equipment status monitoring and manual intervention.

Installation & Maintenance Guidelines

Pre-Installation Preparation

• Disconnect the host power supply and confirm that the on-site voltage meets the 100-240 V AC input range.
• Clean the installation location to ensure no debris blocks the heat dissipation channels.

Mechanical Installation

• Select wall-mounted, cabinet-mounted, or panel-mounted installation based on on-site requirements.
• Fix the housing and base with the included screws to ensure stability.

Electrical Connection

• Connect the power cable to the 100-240 V AC input terminal and confirm secure wiring.
• Connect on-site equipment such as PLCs, sensors, and networks via the I/O interface panel.

System Debugging

• After power-on, check if the display, touch, and keyboard functions are normal.
• Verify the communication status of each interface through built-in diagnostic tools or external monitoring software.

Daily Maintenance

• Regularly check if the cooling fan or heat sink is dusty and clean if necessary.
• Inspect the integrity of sealing gaskets and connecting cables to prevent water or dust intrusion.
• If replacing the keyboard or panel, first turn off the power, remove the original component, insert the new component into the slot, and reattach the front panel with screws.
