XYCOM 4115T Industrial Spare Parts
XYCOM 4115T
The XYCOM 4115T is a 15-inch industrial tablet PC equipped with a touchscreen (1024×768). It is specifically designed for on-site automation, monitoring, and control systems. Integrating a PC host and a display, it can operate reliably for long periods in harsh industrial environments.
1. Main Technical Specifications
| Item | Specification |
|---|---|
| Display | 15.0-inch TFT LCD, resolution 1024×768, supporting 15-pin RGB and DVI-I interfaces |
| Processor | Intel Pentium 4, with a main frequency of 2.0 GHz |
| Memory | 512 MB DDR |
| Hard Disk | 40 GB IDE |
| Operating System | Supports Windows 2000 / Windows XP |
| Expansion Slot | 1 × PCI slot |
| I/O Interfaces | 2 × 2.0 Gbps Ethernet, USB, serial ports, parallel ports, etc. |
| Operating Temperature | 0 °C ~ 50 °C (industrial temperature range optional) |
| Power Supply | 115/230 VAC, 50/60 Hz |
| Dimensions | Approximately 380 mm × 300 mm × 80 mm (including base) |
| Weight | ≈ 8 kg |
2. Product Features
- Integrated Design: Combines the display and host into one unit, saving space and facilitating on-site installation.
- Industrial-Grade Reliability: Features a wide temperature operating range, vibration resistance, dustproof, and moisture-proof capabilities, suitable for workshops and on-site environments.
- Rich Interfaces: Provides various network, serial, parallel, and USB interfaces, enabling easy interconnection with devices such as PLCs, sensors, and fieldbuses.
- Expandability: The PCI expansion slot supports future upgrades of function cards (e.g., fieldbus cards, graphics cards).
- Touch Interaction: Equipped with a capacitive/resistive touchscreen that supports multi-touch, improving operational efficiency.
- Compatibility: Compatible with Windows 2000/XP and supports common industrial automation software (e.g., Pro-Face, Wonderware).
3. Structure and Composition
- Display Module: A 15-inch LCD panel with a backlight and a touch-sensitive layer.
- Host Module: Includes CPU, memory, hard disk, motherboard, power supply unit, and cooling fan.
- Base/Bracket: A metal structure that provides stable support and has built-in heat dissipation channels.
- I/O Panel: Centrally arranges interfaces such as Ethernet, USB, serial ports, parallel ports, DVI-I, and VGA.
- Protective Enclosure: Consists of a metal shell and a plastic protective cover, meeting industrial protection standards (IP30 and above).
4. Typical Application Fields
| Industry | Application Scenarios |
|---|---|
| Manufacturing | Production line monitoring, machine status display, process parameter adjustment |
| Energy | SCADA interfaces and dashboards in power plants and substations |
| Transportation | Monitoring terminals in rail transit and signal control centers |
| Petrochemical | Process control, local operation interfaces in hazardous areas |
| Logistics | Warehouse automation, control panels for conveyor systems |
| Building Facilities | Building automation, HVAC (Heating, Ventilation, and Air Conditioning) monitoring |
5. Installation Key Points
- Environment Preparation: Ensure the temperature and humidity at the installation site are within the device’s operating range, and maintain good ventilation.
- Fixing Method: Use the bolts or brackets provided in the package to fix the base on a solid foundation or wall to prevent vibration.
- Power Connection: Adopt a 115/230 VAC power supply that complies with local standards, and ensure reliable grounding.
- Interface Wiring: Connect Ethernet, USB, serial ports, etc., according to on-site requirements. It is recommended to use shielded cables to reduce electromagnetic interference.
- Software Configuration: After power-on, install or upgrade the operating system and industrial software, and configure network settings, display resolution, and touch calibration.
6. Maintenance Recommendations
| Maintenance Item | Operation Key Points |
|---|---|
| Regular Cleaning | Wipe the screen and enclosure with a clean, soft cloth; do not use corrosive cleaning agents. |
| Heat Dissipation Check | Check the normal operation of the fan every 6 months and clean the dust on the fan and heat sink. |
| Interface Check | Inspect all connecting cables for firmness to prevent communication failures caused by looseness. |
| System Update | Regularly update operating system patches and industrial software versions to improve security and compatibility. |
| Backup | It is recommended to back up key configurations and data to external storage or a network server daily or weekly. |
| Fault Diagnosis | Locate hardware abnormalities (e.g., hard disk, memory) through self-test programs or log files, and replace the corresponding components if necessary. |
————————————————————————————————————-
