XYCOM 97957-101 Panel Module
XYCOM 97957-101
The XYCOM 97957-101 is an operator interface/panel module engineered for industrial automation applications. Boasting low power consumption, a high protection rating, and multi-protocol compatibility, it is ideally suited for scenarios such as process control, machine vision systems, and robotic workstations.
1. Key Specifications
| Parameter | Specification |
|---|---|
| Operating Voltage | 18 V – 30 V DC |
| Protection Rating | IP65 (dust-tight and waterproof) |
| Operating Temperature Range | -20 °C – +60 °C |
| Interfaces | RS-485, Ethernet (10/100 Mbps), XVME |
| Dimensions | 150 mm × 100 mm × 50 mm (W × D × H) |
| Power Consumption | Low-power chip design with passive heat dissipation |
| Storage/Expansion | Supports up to 64 GB High Bandwidth Memory (HBM) |
| Processor | Customizable Intel Xeon series (based on requirements) |
2. Product Features
- Low Power Consumption & Efficient Heat Dissipation: Equipped with low-power consumption chips and a passive heat dissipation structure, the module minimizes energy use and extends service life.
- Modular Design & Hot-Swappable Functionality: The plug-and-play design supports hot swapping, significantly reducing downtime for maintenance and replacement.
- Multi-Protocol Compatibility: Integrated with RS-485, Ethernet, and XVME interfaces, it enables seamless integration into diverse fieldbus environments.
- High Protection Rating: With an IP65 rating, the module delivers reliable performance even in harsh industrial settings.
- Wide Temperature Adaptability: Operating stably within a temperature range of -20 °C to 60 °C, it accommodates various on-site working conditions.
3. Structure and Components
- Power Supply Module: Delivers stable voltage output and supports wide-voltage input.
- Communication Interface Board: Integrates RS-485, Ethernet, and XVME interfaces for multi-channel data transmission.
- Processor Motherboard: Optional Intel Xeon series processor to support high-performance computing needs.
- Heat Dissipation Unit: Passive heat sink ensures effective temperature control during low-power operation.
- Housing: Metal or high-strength plastic enclosure compliant with IP65 standards for robust protection.
4. Typical Application Areas
- Process Control: On-site monitoring and parameter display for continuous production processes in oil, chemical, and natural gas industries.
- Power Systems: Operator interface and status display for substations and distribution automation systems.
- Manufacturing: Operator panels for CNC machine tools and robotic workstations.
- Water Treatment & Environmental Protection: On-site human-machine interaction for sewage treatment plants and waste gas monitoring systems.
- Transportation & Logistics: Monitoring and control of automated warehouses and conveyor systems.
5. Installation and Maintenance Guidelines
- Installation Location: Select a well-ventilated area away from direct sunlight or strong magnetic fields, and ensure the panel front faces the operator.
- Power Supply Check: Verify that the input voltage falls within the 18–30 V range and that the power supply is stable.
- Fixing Method: Secure the module firmly with screws or brackets to prevent loosening caused by vibration.
- Wiring: Connect RS-485, Ethernet, or XVME interfaces strictly according to the wiring diagram and implement proper protection measures.
- Hot Swapping: The module supports hot swapping during system operation, allowing replacement or upgrade without shutting down the entire system.
- Regular Inspection: Conduct checks on housing tightness, heat sink cleanliness, and interface integrity every 6 months.
————————————————————————————————————-
