Xycom NP200 2000T

1. Overview

2. Key Technical Specifications

• Operating Voltage: 18 V – 30 V DC (Typical 24 V)
• Protection Class: IP65 (Dustproof & Waterproof) – Suitable for humid, dusty, or chemically corrosive environments
• Operating Temperature Range: -20 °C to +60 °C
• Communication Interfaces: VME/XVME Slots, RS-485, 10/100 Mbps Ethernet, USB 2.0
• Display/Input: 4-7 inch Color Touchscreen (Resolution: 800 × 480 px) with programmable keyboard or function keys
• Power Management: Low-power design – Standby power consumption < 1 W, Operating power consumption ~3 W
• Dimensions: Approx. 150 mm × 100 mm × 50 mm (Width × Depth × Height)
• Weight: Approx. 0.6 kg

3. Product Features

• Modular Plug-and-Play: Hot-swappable structure allows maintenance and replacement without system shutdown.
• Multi-Protocol Compatibility: Seamless integration with three major industrial networks (VME, RS-485, Ethernet) in one connection, reducing system integration costs.
• High Protection Level: IP65 rating ensures reliable operation in dusty, humid, or mildly chemically corrosive environments.
• Low Power Consumption: Adopts low-power chips and passive heat dissipation to reduce energy consumption and extend service life.
• User-Friendly Interface: Color touchscreen combined with programmable function keys supports custom screens and shortcut operations, improving on-site operational efficiency.
• Wide Temperature Adaptability: -20 °C to +60 °C operating range, suitable for high/low-temperature scenarios such as metallurgy, petrochemicals, and energy.

4. Structure and Composition

• Power Module: Responsible for voltage conversion and power management, with built-in overvoltage and undervoltage protection.
• Communication Interface Board: Integrates VME/XVME, RS-485, Ethernet, and USB interfaces.
• Processor/Control Unit: Based on an industrial-grade MCU, running an embedded operating system to provide real-time data processing.
• Display/Touch Module: 4-7 inch color screen with a capacitive touch layer.
• Function Key Panel: Optional 8-16 key programmable keyboard with dustproof and waterproof keycaps.
• Heat Dissipation Device: Passive heat sink and optional forced fan for temperature control under high loads.
• Housing: Metal frame + sealing gasket, meeting IP65 protection requirements.

5. Typical Application Areas

• Industrial Automation Control Stations: Works with Xycom HMI/PC chassis to realize on-site parameter setting and fault diagnosis.
• Manufacturing Production Lines: Machine debugging, process parameter input, and equipment status monitoring.
• Energy, Petrochemicals, Metallurgy: Provides reliable human-machine interaction in high-temperature, humid, or dusty environments.
• Logistics and Warehousing Systems: Equipment status monitoring, manual intervention, and exception handling.
• Building Automation: Collaborates with building control systems for centralized monitoring and local operation.

6. Installation and Maintenance Guidelines

Pre-Installation Preparation

• Disconnect power and confirm the host power supply is turned off.
• Inspect the front panel gasket for integrity to prevent dust ingress.

Mechanical Installation

• Align the NP200 with the VME/XVME slots and ensure the cable interface is fully inserted.
• Secure the front panel screws and check that the keyboard and panel gaskets are intact.

Electrical Wiring

• Connect the 24 V DC power supply according to the wiring diagram and verify polarity.
• For RS-485 or Ethernet connections, check the locking screws of the cable ports.

Commissioning

• After power-on, confirm the status of each interface through system self-test.
• Load the corresponding driver or configuration file in the upper-level control software to verify data interaction.

Routine Maintenance

• Regular Inspection: Check gaskets, screw tightness, and heat sink dust accumulation every 6 months.
• Hot-Swappable Replacement: Modules can be directly plugged/unplugged during system operation to avoid prolonged downtime.
• Firmware Upgrade: Update firmware via Ethernet or USB interfaces to maintain compatibility and security.
