Xycom XVME-682 70682-101 Processor Module
Xycom XVME-682 70682-101
The Xycom XVME-682 (Model No. 70682-101) is an industrial-grade processor module based on VMEbus. It is specifically designed for field control systems that require high reliability and long-term operation. Featuring a modular structure, it supports plug-and-play functionality in the VME backplane and is compatible with various industrial environments.
Key Specifications
- Processor: High-performance CPU (specific model varies by configuration) with support for real-time operating systems.
- Memory: Optional DDR/SDRAM, with capacity ranging from 256 MB to 2 GB, meeting the needs of large-data processing.
- Storage: Supports NAND Flash or SATA SSD, providing local data storage capabilities.
- I/O Interfaces: Multiple serial ports (RS-232/RS-485), Ethernet (10/100 Mbps), and optional expansion ports for CAN, USB, and PCIe.
- Power Supply: Wide input voltage range of 12 V–24 V, equipped with over-voltage and over-current protection.
- Operating Temperature: -40 °C ~ +85 °C, complying with industrial-grade environmental requirements.
Product Features
- High-Performance Computing: Equipped with mainstream industrial CPUs, it can handle complex control algorithms and large-scale data acquisition.
- Strong Reliability: Adopts anti-interference design and redundant power management, ensuring stable operation in harsh environments with low failure rates.
- Easy Integration: Standard VMEbus interface and rich I/O expansion options enable quick integration into existing systems and compatibility with multiple peripherals.
- Modular Design: CPU, storage, and interface modules can be replaced or upgraded as needed, reducing long-term maintenance costs.
- Long-Term Supply Support: The manufacturer provides at least 5 years of technical support and spare parts supply, making it suitable for long-term project deployment.
Structure and Components
- CPU Motherboard: Houses the processor, memory slots, and storage interfaces.
- VMEbus Interface Card: Responsible for electrical and signal connections with the backplane.
- Optional I/O Expansion Board: Provides additional interfaces such as serial ports, CAN, USB, and PCIe.
- Power Management Module: Enables wide-voltage input, voltage regulation, and protection functions.
- Heat Dissipation System: Includes metal heat sinks and optional fans to ensure temperature control under high loads.
Typical Application Fields
- Industrial Automation Control: Serves as the core computing unit for PLC, DCS, and SCADA systems.
- Real-Time Data Acquisition: Used in high-speed sensor networks and process monitoring.
- Communication Gateway: Enables bridging for industrial Ethernet and fieldbuses (e.g., CAN, Profibus).
- Military and Aerospace: Suitable for embedded computing platforms requiring high reliability and anti-interference capabilities.
- Energy Management: Applied in on-site monitoring and control for power, oil, and natural gas industries.
Installation and Maintenance Guidelines
- Installation: Align the module with the slots on the VME backplane and insert it firmly to ensure good contact between the pins and the backplane. After connecting power, network, and peripheral cables, perform a power-on self-test.
- Heat Dissipation: Check that heat sinks and fans are securely installed, and maintain good ventilation inside the chassis. In high-temperature environments, additional fans or forced air cooling are recommended.
- Firmware Upgrade: Download the latest BIOS/firmware via Ethernet or USB interfaces. Always back up the original configuration before upgrading.
- Troubleshooting: Use self-test LED indicators or remote monitoring software to check error codes. Common faults include power anomalies, memory errors, and interface failures; replace the corresponding module according to the error code.
- Regular Maintenance: Clean dust and check connector tightness every 6–12 months. Verify that the power supply and heat dissipation system are functioning properly to extend the module’s service life.
————————————————————————————————————-
