ABB 5SHY35L4510

5SHY35L4510 is an asymmetric Integrated Gate-Commutated Thyristor (IGCT) module from the ABB 5SHY series. Designed specifically for high-voltage and high-current power electronic systems, it is commonly used in medium-frequency (< 1 kHz) power conversion, wind power, photovoltaic (PV), and industrial drive applications. The product adopts a compact TO-247AB package, integrating an IGCT chip, anti-parallel diode, and gate drive circuit to deliver efficient, low-loss switching performance.

Key Technical Specifications

• Rated Voltage (VDRM): 4500 V
• Rated Current (ITGQM): 4000 A
• Short-Circuit Withstand Current (ITSM): 32 kA (approximately 32 × 10³ A)
• Forward Voltage Drop V(T0): 1.4 V
• On-State Resistance rT: 0.325 mΩ
• DC Link Voltage: 2800 V
• Package: TO-247AB, dimensions approximately 439 mm × 173 mm × 41 mm, weight approximately 2.5 kg
• Heat Dissipation: Natural cooling or forced air cooling, compatible with heat sinks or fans
• Operating Frequency: Approximately 1 kHz (medium frequency)
• Environmental Resistance: Wide temperature range, compliant with RoHS environmental directives

Product Features

• Asymmetric Structure: Enhances switching efficiency and reduces turn-on/turn-off losses.
• High Current/High Voltage: Suitable for 4 kA-class high-current and 4.5 kV-class high-voltage power conversion.
• Fast Turn-Off Capability: High snubberless turn-off rating, ideal for medium-frequency power devices.
• High Reliability: Adopts advanced chip technology, offering strong electromagnetic interference (EMI) resistance and long service life.
• Modular Design: Integrates IGCT chip, diode, and gate drive to simplify system wiring and facilitate installation, maintenance, and component replacement.
• Easy Control Interface: Supports AC or DC power supply, provides status feedback, and enables easy connection with upper-level systems such as PLCs and frequency converters.

Structure and Composition

• IGCT Main Chip: Core commutation thyristor that realizes efficient current commutation.
• Anti-Parallel Diode: Provides a freewheeling path to protect the IGCT from current surges during turn-off.
• Gate Drive Circuit: Internally integrated to deliver precise gate pulses and reduce external wiring inductance.
• Heat Sink/Radiator: Metal heat dissipation component, compatible with natural or forced air cooling.
• Terminal Block: Adopts O-type or Y-type connection terminals, selectable based on actual wiring requirements.

Typical Application Fields

• Wind Power Inverters: High-voltage commutation in large-power wind turbines (≥ 10 MW).
• PV Inverters: DC-AC conversion in large-scale photovoltaic power plants.
• Industrial Drives: High-power motor drives, frequency converters, and servo systems.
• Power Electronic Conversion: Medium-frequency soft switching, UPS, and High-Voltage Direct Current (HVDC) transmission.
• Other High-Voltage and High-Current Scenarios: Such as electrolysis, electric arc furnaces, and rail transit traction power supply.

Installation and Maintenance Guidelines

• Installation Method: Modular structure supports rail or panel mounting. Ensure crimping quality of terminal blocks to avoid damage to insulation layers.
• Heat Management: Forced air cooling is recommended under rated power. Check if the thermal interface material (TIM) between the heat sink and module is intact.
• Power Supply: The gate drive circuit can use AC or DC power supply; be sure to provide a regulated power supply according to specifications.
• Status Monitoring: Utilize the module’s status feedback signals (e.g., gate current, temperature) for real-time monitoring to enable early warning.
• Regular Inspection: Inspect terminal tightness, heat sink cleanliness, and whether there are abnormal hot spots or corrosion on the module surface every 6-12 months.
• Replacement and Spare Parts: The module is detachable and can be replaced as a whole in case of failure. It is recommended to maintain 1-2 units in spare parts inventory to minimize downtime.

————————————————————————————————————-
