ABB DO880

The DO880 is a 16-channel 24 V digital output module for the ABB 800xA system, suitable for single or redundant configurations. It features current limiting, over-temperature protection, and EMC suppression, and is commonly used for field device control in process automation, DCS, and PLC systems.

Key Technical Specifications

• Model/Ordering Code: DO880
• Number of Channels: 16
• Output Voltage: 24 V DC
• Rated Output Current: 0.5 A per channel (up to 2 A for specific models)
• Protection Functions: Current limiting, over-temperature protection, short-circuit protection, EMC suppression, photoelectric isolation
• Operating Temperature Range: -20 °C to +60 °C
• Protection Class: IP20
• Dimensions/Weight: Approximately 538 mm × 30 mm × 23 mm, weighing around 1 kg

Product Features

1. High Reliability: Equipped with high-side drivers and isolation barriers, ideal for harsh industrial environments.
2. Flexible Configuration: Supports standalone or redundant operation, enabling free combination based on on-site requirements.
3. Diagnostics and Indicators: Each channel is fitted with an LED status indicator, supporting fault diagnosis information reporting.
4. Strong Compatibility: Compatible with multiple control platforms such as ABB 800xA, AC500, and AC800M.

Structure and Components

• Module Body: Contains 16 independent digital output channels, each with a high-side driver that provides current limiting and over-temperature protection.
• Connection Terminals: Standardized 24 V DC output terminals, supporting screw or quick wiring.
• Communication Interfaces: Communicates with upper-level systems via Modulebus, PROFIBUS DP, or IEC 61850.
• Indicators and Shielding: Includes per-channel LED indicators, EMC suppression components, and photoelectric isolation barriers.

Typical Application Fields

• Process Automation: Driving valves and relays in continuous production processes such as chemical, petroleum, natural gas, and pharmaceutical industries.
• Power and Energy: DCS monitoring in power plants and distribution automation.
• Manufacturing: Control of production line equipment, robots, and servo/stepper motors.
• Water Treatment and Environmental Monitoring: Signal output for pump stations, valves, and sensors.

Installation and Maintenance Guidelines

• Environmental Requirements: Install in a dry, well-ventilated cabinet free of corrosive gases, and maintain the operating temperature within the rated range.
• Power Supply: Provide a stable 24 V DC power supply to prevent module damage caused by voltage fluctuations.
• Wiring Specifications: Use cables and connectors that meet specifications, ensuring secure wiring with no loosening.
• Software Configuration: Perform channel mapping and diagnostic parameter settings through ABB programming software (e.g., 800xA Engineering).
• Regular Inspection: Check that LED indicators, communication interfaces, and output currents are functioning properly; upgrade firmware when necessary.
• Fault Diagnosis: Use the module’s built-in diagnostic information to quickly locate short circuits, overloads, or communication anomalies.
