ABB REF543KM129AAAB

Product Overview

The ABB REF543KM129AAAB is a feeder terminal protection device manufactured by ABB, designed to provide protection, monitoring, and control functions for feeders in power systems. This device is suitable for harsh industrial environments, capable of withstanding extreme temperatures, vibrations, and shocks to ensure stable operation of power systems.

Specifications

• Model: REF543KM129AAAB
• Brand: ABB
• Series: REF Series
• Product Type: Feeder Terminal Protection Device
• Supported Protocols: Modbus RTU, Modbus TCP/IP
• Communication Speed: 10/100 Mbps
• Operating Temperature: -20°C to 60°C (some sources cite -20°C to 70°C)
• Dimensions: 120 mm x 80 mm x 30 mm (some sources cite 100 mm x 50 mm x 25 mm)
• Weight: 0.5 kg (some sources cite 2.1 kg)
• Input Voltage: 24VDC, 110VAC, 220VAC
• Output Voltage: 5VDC
• Protection Functions: Overcurrent, undervoltage, overvoltage, ground fault, phase reversal protection
• Measurement Range: 45Hz–65Hz (for frequency relay)
• Setting Accuracy: 0.1Hz
• Response Time: ≤10ms
• Output Method: Relay contacts
• Operating Humidity: 0%–95% RH (non-condensing)
• Mounting Options: Panel-mounted or 35mm DIN rail-mounted
• Protection Rating: IP67 (some sources cite IP45)

Key Features

1. Fast Response: Monitors feeder current, voltage, and other parameters in real time. Detects anomalies (e.g., overloads, short circuits) and swiftly disconnects circuits to prevent equipment damage.
2. High Reliability: Built with premium components and advanced manufacturing processes for stable performance in harsh electrical environments and extended lifespan.
3. Smart Management: Equipped with communication interfaces for integration with host computers or centralized monitoring systems, enabling remote management.
4. Multi-Protection Functions: Includes basic overload/short-circuit protection, as well as undervoltage, overvoltage, and ground fault protection to meet diverse power system needs.
5. Easy Installation & Maintenance: Compact design, user-friendly interface, and comprehensive fault diagnostics simplify setup and upkeep.
6. High-Precision Measurement: Uses electromagnetic current transformers for high accuracy, linearity, and fast response.
7. Versatile Communication: Supports Modbus RTU, Modbus TCP/IP, and other protocols for seamless industrial automation integration.
8. Industrial Compliance: Meets IEC 60529 IP67 standards for harsh industrial applications.

Structure & Components

The ABB REF543KM129AAAB consists of:

• Main Control Unit: Processes input signals and executes protection logic.
• I/O Modules: Collects current/voltage signals and outputs control commands.
• Communication Interface: Supports Modbus RTU/TCP/IP for industrial automation connectivity.
• Relay Contacts: Triggers circuit-breaking actions for protection.
• Power Module: Ensures stable input/output voltage.
• Enclosure: IP67-rated housing protects against dust and moisture.

Applications

The REF543KM129AAAB is widely used in:

• Power System Protection: Safeguards feeders in transmission/distribution lines.
• Substation Applications: Monitors and protects feeders in substations.
• Industrial Power Distribution: Ensures stable supply for industrial equipment and production lines.
• Energy Production: Protects feeders in coal plants, hydropower stations, and wind farms.
• Railway Electrification: Secures feeders in railway power systems.
• Transportation Tunnels: Monitors tunnel power systems for traffic infrastructure.
• Industrial Automation: Integrates with SCADA systems for real-time data and management.

Installation & Maintenance

• Installation: Compatible with panel or 35mm DIN rail mounting.
• Maintenance: Features intuitive diagnostics for efficient troubleshooting.
• Upkeep: Regular checks of relay contacts, I/O modules, and communication interfaces are recommended.
• Fault Diagnosis: Built-in diagnostics enable quick fault identification.
• Software Updates: Firmware upgrades optimize performance and expand functionality.

———————————————————————————————————————————
