Product Specifications

• 17-32V DC (1SBL359061R5111)
• 50-90V DC (1SBL359061R5511)
• 63-113V DC (1SBL359061R6111)
• 90-150V DC (1SBL359061R6611)

Product Features

• Built-in Auxiliary Contact: Equipped with 1 integrated auxiliary contact to realize flexible signal feedback functions.
• Screw Terminal Connection: Adopts screw-type terminals for convenient wiring and firm fixation.
• Wide Voltage Design: Tolerates large control voltage fluctuations to ensure stable operation under unstable power grid conditions.
• Built-in Surge Protection: Integrated surge suppression module reduces panel power consumption and supports compact electrical cabinet layout solutions.
• Modular Block Structure: The block-style housing allows easy expansion of additional auxiliary contact modules and matched accessories.
• Thermal Overload Relay Compatibility: Compatible with matched thermal overload relays to build a complete motor protection control system.

Structure & Composition

1. Electromagnetic System: Composed of coil, iron core and armature, adopting clapper-type mechanical structure.
2. Contact System: Including main contacts and auxiliary contacts, responsible for circuit closing and breaking actions.
3. Arc Extinguishing Device: Designed to eliminate electric arcs generated during contact breaking.
4. Auxiliary Contact Assembly: Equipped with NO/NC contacts for circuit monitoring, signal control and status indication.
5. Housing & Insulating Components: Provides mechanical protection and electrical insulation for internal parts.
6. Connection Terminals: Interface terminals for main power circuit and control circuit wiring.

Application Fields

• Motor Control: Start, stop, reverse and plugging braking control of DC motors
• Lighting Control: On-off switching management for DC lighting systems
• General DC Load Control: Switching control of all types of DC electrical loads
• Electromagnetic Equipment Control: Control for lifting electromagnets, solenoid valves, clutch electromagnetic coils and other electromagnetic actuators
• Industrial Automation: DC circuit switching in industrial automation systems and power control systems
• Industrial & Commercial Deployment: All application environments requiring reliable DC circuit switching and control performance

Installation & Maintenance Guidelines

Installation Requirements

• Mounting Location: Keep away from strong magnetic fields (transformers, permanent magnets) and high-temperature heat sources during installation.
• Wiring Terminal Rules:

  Fastening Torque: Control the locking torque of terminal screws within the factory-specified range.

  • Adopt wires with cross-sectional area ≥10mm² to avoid abnormal heating
  • Do not apply grease or foreign substances on terminal surfaces
  • Install gaskets to prevent terminal loosening
• Mechanical Support: Equip matched insulating support insulators near wiring terminals to avoid excessive stress on wire outlets.
• Mechanical Stress Prevention: Avoid external mechanical stress acting on contact-matched wiring terminals.

Maintenance Precautions

• Electrical Life Management: Standard electrical life tests are conducted under resistive load conditions. For inductive load circuits (LR≥1ms), surge absorption devices must be equipped to prevent shortened service life and faulty circuit breaking.
• Capacitive Load Protection: Pre-charging measures are mandatory for capacitive load circuits. The closing voltage of the contactor shall be controlled within 20V to avoid contact adhesion failure.
• Back EMF Suppression: It is recommended to install non-linear resistors (preferred varistor parameters: maximum energy tolerance 1J, rated voltage 1.5-2 times of circuit working voltage) to restrain back electromotive force.
• Impact Resistance: Avoid collision, dropping and mechanical impact during transportation and on-site operation. Damaged contactors after impact are forbidden for reuse.
• Wiring Polarity: The contacts have fixed polarity. Complete wiring strictly in accordance with official wiring diagrams.
