I. Overview

II. Parameters

• Model: UFC760BE142
• Part number: 3BHE004573R0142
• Number of I/O points: 16 points
• I/O type: Digital input/output, analog input/output
• Digital input/output range: DC 24V
• Analog input/output range: -10V to +10V
• Operating temperature: -20°C to +70°C
• Power supply mode: 24V DC
• Surge voltage: 2500V
• Isolation voltage: 2500V
• Response time: <1ms
• Power consumption: <10W
• Protection level: IP20
• Dimensions: 230mm×170mm×60mm
• Weight: Approximately 2kg
• Installation method: Rail mounting
• Connection method: Terminal block

III. Product Features

• High performance: The module supports vector control, ensuring high-precision control and efficient operation of the motor.
• High reliability: High-quality components and advanced manufacturing processes are adopted to ensure long-term reliable operation of the product.
• Ease of use: The module has a simple design and easy operation, suitable for various industrial environments.
• Strong compatibility: It supports multiple communication protocols such as Modbus, Profibus, Ethernet, etc., facilitating integration with existing systems.
• Modular design: It is convenient for installation, maintenance and expansion, improving the flexibility and maintainability of the system.

IV. Structure and Composition

• Control board: Responsible for processing and controlling signals to achieve precise control of equipment.
• Interface board: Used to connect the control system and equipment, supporting multiple communication protocols.
• Power module: Provides a stable 24V DC power supply to ensure the normal operation of the module.
• Protection module: Provides overvoltage, overcurrent, overheating and other protection functions to ensure the safety of equipment.
• Communication module: Supports multiple communication protocols to realize communication with upper computers or other equipment.

V. Application Fields

• Industrial automation control systems: Used to control and monitor various industrial equipment.
• Power system monitoring and management: Used for monitoring and control of power systems.
• Intelligent building control: Used for control of building automation systems.
• Intelligent transportation systems: Used for traffic signal control and monitoring.
• Energy management systems: Used for efficient management and control of energy.
• Manufacturing industry: Used for automatic control of production lines.
• Metallurgy, petroleum, chemical industry, papermaking, textile, electronic manufacturing, tobacco, plastic machinery, electric power, water conservancy, water treatment, municipal engineering, boiler heating, energy, power transmission and distribution and other fields: Used for control and monitoring of various industrial processes.

VI. Installation and Maintenance

• Installation method: The module adopts rail mounting, which is convenient for installation and maintenance.
• Installation steps:
  1. Install the module on the rail.
  2. Connect the power cord and signal line.
  3. Check whether all connections are firm.
• Maintenance suggestions:
  • Regularly check the connection and operation status of the module.
  • Clean the surface of the module to prevent dust accumulation.
  • Check whether the power supply and signal lines are normal.
  • Conduct regular performance tests to ensure the normal operation of the module.
