ATLAS PF3107-C-IB2-HW Input/Output Module
ATLAS PF3107-C-IB2-HW
1. Overview
2. Specifications
|
Specification
|
Description
|
|---|---|
|
Model
|
PF3107-C-IB2-HW
|
|
Input Voltage
|
90-240V AC, 50/60Hz
|
|
Output Power
|
Approx. 300W
|
|
Communication Interface
|
PROFINET (IB)
|
|
Tool Compatibility
|
Tensor 3 to Tensor 7 series (including Tensor 5, 7, etc.)
|
|
Control Functions
|
Torque Control, Angle Control, Combined Control
|
|
Data Processing
|
Supports data recording, curve storage and real-time transmission for each tightening process
|
|
Program Capacity
|
Supports up to 255 tightening programs
|
_______________________________________________________________________________________________________
3. Product Features
- High-Precision Control: Adopts advanced control algorithms to control torque and angle within an extremely narrow error range, ensuring the fastening quality of connectors.
- Powerful Data Traceability: Built-in data processing function, key data of each tightening process can be recorded and uploaded to the MES system, facilitating quality traceability.
- Multi-Protocol Support: In addition to PROFINET, it usually supports industrial network protocols such as DeviceNet and Ethernet/IP, making it easy to integrate into existing production lines.
- Modular Design: Compact structure, easy to install in combination with electric tools or use as an independent control unit.
_______________________________________________________________________________________________________
4. Structure and Composition
- Power Supply Module: Responsible for converting industrial power into low-voltage DC power required inside the controller.
- Control Core Board: Includes CPU, RAM, ROM and memory for storing tightening programs.
- Communication Module: Communication card supporting industrial network protocols such as Profinet, DeviceNet or Ethernet/IP.
- I/O Interface Board: Used to connect electric tools, sensors (such as torque sensors, angle sensors) and external devices.
- Display and Operation Panel: Some models may be equipped with an LCD display or operation buttons for on-site engineers to set parameters and diagnose faults.
_______________________________________________________________________________________________________
5. Application Fields
- Automotive Manufacturing: Tightening of key bolts for engines, gearboxes, chassis and body structural parts.
- Aerospace: High-precision assembly of aircraft structural parts and engine components.
- Electronic Appliances: High-precision assembly of battery modules, electric drive systems and electronic products.
- Heavy Machinery: Structural connection of construction machinery and rail transit equipment.
_______________________________________________________________________________________________________
6. Installation and Maintenance
Installation Method
Wiring Requirements
Maintenance
————————————————————————————————————-
