ATLAS PF4002-C-PB-HW Control Panel
ATLAS PF4002-C-PB-HW
1. Overview
The ATLAS PF4002-C-PB-HW is a high-performance control module designed specifically for industrial automation in Atlas Copco’s PF4000 series. This model is usually integrated with a PROFIBUS communication interface (marked as PB), mainly used to drive and control Atlas Copco’s intelligent electric tightening tools (such as Tensor ST, ES, ETX series). It provides stable power supply, focus control and tightening process data communication functions in high-end assembly scenarios.
_______________________________________________________________________________________________________
2. Key Technical Parameters
|
Parameter Category
|
Details
|
|---|---|
|
Communication Protocol
|
PROFIBUS-DP (Hardware Integrated Interface)
|
|
Power Input
|
100–240V AC, 50/60Hz
|
|
Tool Compatibility
|
Supports Atlas Copco Tensor ST/ES/ETX series and other intelligent electric tightening tools
|
|
Control Mode
|
Torque Control, Angle Control, Multi-stage Tightening, Combined Control
|
|
Rated Power
|
150W
|
|
Dimension/Weight
|
319mm x 173mm x 415mm; Weight approx. 12.64kg (26.45 lbs)
|
|
Operating Temperature
|
41°F – 104°F (approx. 5°C – 40°C)
|
_______________________________________________________________________________________________________
3. Product Features
- Modular Integration: Integrates PROFIBUS communication module and power control function into one, reducing additional wiring and installation space.
- High Reliability: Complies with multiple EU regulations (such as RoHS, EMC, etc.), with industrial-grade protection level, suitable for harsh production environments.
- Data Interaction Capability: Enables real-time collection of tightening data, fault diagnosis, program parameter download and remote monitoring.
- Multi-language Support: The supporting software supports multi-language (including Chinese) display, facilitating the deployment of global production lines.
_______________________________________________________________________________________________________
4. Structure and Composition
- Compact Controller: PF4000-C-PB-HW main control unit.
- HMI (Human-Machine Interface): Used for local parameter setting and status display.
- PROFIBUS Communication Interface: Used to connect PLC or upper computer system.
- Power Management Module: Responsible for providing stable power output to electric tools.
_______________________________________________________________________________________________________
5. Application Fields
- Aerospace: Bolt fastening and quality traceability.
- Automotive Manufacturing: Bolt fastening after engine assembly and body welding.
- Energy Equipment: Such as bolt fastening of wind turbine blades.
- Electronics and Electrical: Assembly of high-voltage electrical equipment.
_______________________________________________________________________________________________________
6. Installation and Maintenance
Installation Method
Supports standard industrial cabinet installation or production line embedded installation, usually connected to PLC or industrial PC through PROFIBUS cables.
Maintenance Recommendations
- Regular Inspection: Since it integrates a power module, it is recommended to regularly check the connection status of the power input port and communication interface.
- Firmware Update: Keep the controller firmware version updated to ensure compatibility with the latest tool firmware and communication protocols.
- Environment Inspection: Avoid being in excessively high temperature or high humidity environment for a long time, so as not to affect the stability of communication chips and power modules.
————————————————————————————————————-
