Beckhoff CP3915-0000

The Beckhoff CP2915‑0000 is an industrial-grade multi-touch panel based on PC control technology. It features original German design and is suitable for various automation sites. Integrating display, touch control, communication, and I/O functions, it can be directly used as a Human-Machine Interface (HMI) or a front-end display terminal for upper-level computers.

Key Technical Specifications

• Display Screen: 7-inch TFT color touchscreen with a resolution of 800 × 480 pixels
• Touch Control Method: 10-point capacitive touch, supporting handwriting and gesture operations
• Processor: Optional embedded CPU from Intel Atom® or AMD GX series, running TwinCAT 3 real-time control software
• Memory/Storage: 2 GB DDR3 RAM, 16 GB eMMC (expandable with SSD)
• Communication Interfaces: EtherCAT, Ethernet/IP, PROFINET, Modbus TCP, CANopen, USB 3.0, RS-232/485
• I/O: Built-in digital inputs/outputs (8 DI + 8 DO), analog inputs (4 AI), and analog outputs (2 AO)
• Power Supply: 24 V DC (12 V DC optional) power input, with a power consumption of approximately 15 W
• Operating Environment: Temperature range 0 ~ 55 °C, humidity range 10% ~ 90% (non-condensing), protection class IP20

Product Features

• Open Hardware and Software Platform: Based on Beckhoff TwinCAT 3, supporting multiple programming methods such as IEC 61131-3, C/C++, and MATLAB/Simulink.
• High Integration: Integrates display, touch control, communication, and I/O in one unit, reducing on-site wiring and external modules.
• Real-Time Performance: Equipped with EtherCAT master function, achieving cycle times as low as 31 µs to meet high-speed motion control requirements.
• Modular Expansion: Additional digital/analog/fieldbus modules can be connected via EtherCAT Couplers like EK1100/EK1200.
• Industrial-Grade Reliability: Features anti-vibration and anti-electromagnetic interference design, complying with the IEC 60730-1 safety standard.
• Multi-Language UI: Supports Chinese, English, German, and other languages for user interfaces, facilitating deployment in international projects.

Structure and Composition

• Front Panel: Touch display screen, function keys (Back, Home, Emergency Stop), and indicator lights.
• Internal Mainboard: CPU, memory, storage, EtherCAT main control chip, and I/O expansion interfaces.
• Power Module: Converts 24 V DC input to internal working voltage, with overvoltage/undervoltage protection.
• Heat Dissipation System: Passive heat sinks and optional fans ensure thermal stability during long-term operation.
• Connection Terminals: DIN-Rail mounting brackets, screw fixing holes, and pin headers for external I/O interfaces.

Typical Application Areas

• Machine Vision Systems: Serves as a front-end interface for image acquisition and parameter adjustment.
• Packaging and Printing Machinery: Enables real-time monitoring of production status and quick recipe switching.
• Automated Assembly Lines: Supports human-machine interaction, process switching, and fault diagnosis.
• Process Control: Used for on-site monitoring and adjustment in industries such as chemical engineering, food, and beverages.
• Laboratory and R&D Platforms: Facilitates rapid prototype development and algorithm debugging.

Installation and Maintenance Guidelines

1. Installation: Fix the panel using the DIN-Rail method, ensure the panel is level, connect the power supply and EtherCAT bus, then perform a power-on self-test.
2. Wiring: Use standard wiring terminals, keep signal wires separate from power wires to avoid electromagnetic interference.
3. Software Configuration: Add the CP2915-0000 as an EtherCAT slave in the TwinCAT XAE environment, download the configuration, and conduct online debugging.
4. Daily Inspection: Regularly check the power supply, dust accumulation on heat sinks, and confirm the response sensitivity of the touchscreen.
5. Firmware Update: Download the latest firmware from the official Beckhoff website and update it using TwinCAT to obtain new functions and security patches.

————————————————————————————————————-
