Schneider AEG 120-085-001 Modular Distribution Cabinet Product
Schneider AEG 120-085-001
Schneider AEG 120-085-001 is a modular low-voltage distribution cabinet designed for industrial low-voltage power distribution. Adopting a Rear Mounted Busbar (MLS) structure, it is compatible with low-voltage switching components compliant with IEC 60947-4-1 standard, offering multiple functional units including circuit breakers, contactors, relays and measuring instruments. It supports on-site quick assembly or replacement, significantly shortening the construction cycle.
Key Technical Specifications
Product Features
- Modular Design: All functional units (circuit breakers, contactors, relays, measuring instruments, etc.) are standardized modules, enabling free combination or quick replacement on-site as per requirements.
- Rear Mounted Busbar Structure: Busbars are located at the rear of the cabinet, facilitating maintenance, reducing electromagnetic interference and providing better heat dissipation space.
- High Reliability: Equipped with low-voltage switching components meeting IEC 60947-4-1 standard, it features multiple protection functions against short circuit, overload, undervoltage and undercurrent.
- Compact & Flexible: Compact overall size fits various cabinet layouts; modularity supports later-stage function expansion.
- Easy Installation: Standardized terminals and pre-assembled busbar system greatly reduce wiring workload and improve on-site construction efficiency.
Structure & Components
- Cabinet Body: Steel frame for mechanical support and protection
- Rear Mounted Busbar (MLS): Busbar at the cabinet rear, carrying the main current path
- Functional Modules: Plug-and-play modules including circuit breaker, contactor, relay and measuring instrument modules, configurable per project needs
- Terminal Blocks: Standardized terminals for convenient on-site wiring
- Cooling & Heat Dissipation Device: Natural ventilation or optional fans to ensure components operate within rated temperature range
Typical Application Fields
- Industrial automation power distribution systems
- Power distribution cabinets for machine tools and CNC equipment
- Energy management and power distribution monitoring systems
- Building electromechanical systems (e.g. building automation)
- Electrical control cabinets for process control and production lines
Installation & Maintenance Essentials
- On-site Inspection: Confirm the cabinet installation location meets requirements for ventilation, support and protection.
- Busbar Connection: Fix the rear mounted busbar at the cabinet rear with dedicated bolts to ensure good contact.
- Module Insertion: Insert corresponding modules into reserved slots according to functional needs and ensure the buckles are locked in place.
- Wiring: Adopt standardized terminal blocks for phase line, neutral line and protective grounding wiring with clear identification.
- Commissioning: Check tightness of all bolts and terminals before power-on; verify insulation status with an insulation resistance tester.
- Daily Maintenance: Regularly inspect fasteners of busbars and modules, clean dust, monitor temperature and contact resistance, and replace aging modules or terminals in a timely manner.
