Eaton ATC-300+6D32360G45

Overview

Specifications

• System Voltage Range: 120 ~ 600 V
• Operating Frequency: 50 Hz or 60 Hz
• Phase: Single-phase, Three-phase
• Protection Functions: Undervoltage/underfrequency, overvoltage/overfrequency, three-phase voltage imbalance, three-phase rotation protection, etc.
• Communication Interfaces: RS‑232, Modbus
• Display: LCD panel for real-time monitoring of power status
• Enclosure Material: High-strength metal enclosure with protection level meeting industrial on-site requirements

Product Features

• Multifunctional Performance: Flexible programming support for multiple operating modes; complete protection for voltage, frequency and phase sequence.
• Compact Design: Panel-mounted installation for easy on-site arrangement.
• Reliability: High-quality electronic components ensure anti-interference, high temperature resistance and adaptability to harsh industrial environments.
• Easy Maintenance: LCD displays fault information for quick problem location; regular maintenance guarantees long-term stable operation.

Structure and Composition

• Microprocessor Motherboard: Implements control logic and communication functions.
• Power Monitoring Module: Real-time collection of voltage and frequency, and execution of protection.
• Input/Output Terminal Block: Supports single-phase and three-phase wiring with protective covers.
• Communication Interface Board: Provides RS‑232 and Modbus interfaces.
• Display Panel: LCD screen shows power status and fault codes.
• Enclosure: High-strength metal structure with dustproof and waterproof properties.

Application Fields

• Energy and Power: Main and backup power switching in power plants and substations.
• Metallurgy and Iron & Steel: Power supply guarantee for high-voltage motors and steelmaking furnaces.
• Chemical and Petrochemical: Power reliability for key process equipment.
• Mining and Ports: Power management for large machinery and conveying systems.
• Rail Transit: Automatic switching of train power supply systems.

Installation and Maintenance

• Installation Requirements: Dry, ventilated environment without strong electromagnetic interference; ensure firm wiring and compliance with electrical specifications.
• Wiring Guide: Perform single-phase or three-phase wiring according to the manual, paying attention to phase sequence and grounding.
• Commissioning Steps: After power-on, check the LCD display and verify the normal operation of communication interfaces (RS‑232/Modbus).
• Daily Maintenance: Regularly inspect terminal blocks, remove dust, and check the sealing of protective covers; quickly troubleshoot according to fault codes.

————————————————————————————————————-
