Eaton URTDII-02

Overview

Key Specifications

• Power Supply Voltage: 24 – 48 V DC (24 V DC compatible)
• Power Consumption: Approximately 1 W (low-power design)
• Operating Temperature Range: -20 °C ~ +55 °C (-4 °F ~ +131 °F)
• Storage Temperature Range: -40 °C ~ +85 °C (-40 °F ~ +185 °F)
• Relative Humidity: 0% ~ 95% RH (non-condensing)
• Installation Category: I (fieldbus installation)
• Dimensions: Approximately 7.40 in (188 mm) height × 2.00 in (51 mm) width × 7.77 in (197 mm) depth, equipped with multiple interfaces (power supply, RTD, RS-485 Modbus, fiber optic, etc.)

Product Features

• Low Power Consumption: Only 1 W, ideal for power-constrained field environments.
• Wide Temperature/Humidity Adaptability: Meets the harsh environmental requirements of industrial sites.
• Multi-Interface Design: Offers power supply, RTD, RS-485 Modbus, and fiber optic interfaces for easy integration with different upper-level systems.
• Modular Structure: Compact size facilitates installation in cabinets or fieldbus panels.
• Reliability: Industrial-grade design compliant with IEC 60947-4-1 standard, suitable for long-term operation.

Structure and Composition

• Power Input Terminals (PWR IN 1, PWR IN 2)
• RTD Sensor Ports (multiple 2-wire/3-wire RTD interfaces)
• Communication Interfaces: RS-485 Modbus (J11) and Fiber Optic Interface (FIBER OPTIC)
• Control Switches (S1, S2)
• Nameplate: Contains model number, calibration number, serial number, and other information

Typical Application Fields

• Process Industry: Production lines requiring precise temperature monitoring in chemical, petroleum, metallurgy, and other sectors.
• Building Automation: Temperature feedback for Heating, Ventilation, and Air Conditioning (HVAC) systems.
• Energy Management: Temperature monitoring in power plants and substations.
• Manufacturing: Temperature control for CNC machine tools, packaging equipment, etc.

Installation and Maintenance Guidelines

• Power Supply Check: Ensure the power supply voltage is within the range of 24 – 48 V DC to avoid overvoltage or undervoltage.
• Wiring Specifications: Follow the wiring requirements for 2-wire or 3-wire RTD interfaces, and keep the terminal connections tight to prevent loosening.
• Environmental Requirements: Install the module within the specified operating temperature and humidity range, avoiding direct exposure to extreme environments.
• Communication Configuration: Set the address and baud rate according to the fieldbus or Modbus network to ensure normal communication with the upper-level system.
• Regular Inspection: Perform a functional self-test every 6 – 12 months, check the power supply, interfaces, and sealing conditions, and replace aging components in a timely manner.
