GE IS220PSVOH1B

The GE IS220PSVOH1B is a high-performance servo/power module launched by General Electric (GE) for industrial automation and control systems. It can function as a variable frequency drive, servo control card, or power supply unit. Compatible with multiple communication protocols (including RS-232, RS-485, CAN bus, and MIL-STD-1553B), it is suitable for harsh industrial environments, featuring an IP65 protection rating and a wide operating temperature range.

Key Specifications

• Input Voltage: Common versions support 100 ~ 240 VAC
• Output Voltage: 24 V DC (adjustable)
• Rated Power: Approximately 220 W (120 W – 240 W for some specifications)
• Rated/Peak Current: 1.5 A continuous, approximately 3 A peak; maximum output current up to 10 A
• Operating Temperature: -40 °C ~ +85 °C
• Protection Rating: IP65 (dustproof and waterproof)
• Dimensions/Weight: Approximately 200 mm × 150 mm × 60 mm, weight 1 ~ 2.5 kg
• Communication Interfaces: RS-232, RS-485, CAN bus, MIL-STD-1553B, Ethernet (EtherNet/IP, Profinet, etc.)
• Control Modes: Three closed-loop control modes – position, speed, and torque

Product Features

• High Efficiency and Reliability: With an efficiency of over 88% and high power density, it is suitable for industrial equipment that operates for long periods.
• Modular Design: Compact size and plug-in card design facilitate quick assembly, replacement, and maintenance.
• Multi-Protocol Compatibility: Supports multiple fieldbuses and industrial Ethernet, enabling easy integration with PLCs, HMIs, and upper-level systems.
• Comprehensive Protection Functions: Equipped with overvoltage, overcurrent, short-circuit, and overtemperature protection to enhance system safety.
• Wide Temperature Range and Protection Rating: IP65 protection and an operating range of -40 °C ~ +85 °C ensure reliable operation in harsh environments.

Structure and Composition

• Power Conversion Unit: Responsible for converting wide-range AC input into regulated DC output.
• Control Processor: Based on GE’s self-developed real-time control chip to implement closed-loop control algorithms.
• Communication Module: Includes interface circuits for RS-232/RS-485, CAN, and Ethernet.
• I/O Interface Board: Provides connection terminals (such as M12 and screw terminals) for motors, sensors, and actuators.
• Heat Dissipation and Protective Enclosure: Aluminum alloy enclosure with passive heat sinks, meeting IP65 protection requirements.

Typical Application Areas

• Packaging machinery, printing, and textile equipment (high-speed motion control)
• Food processing and robotics (precision position/speed control)
• CNC machine tools and laser processing (high-rigidity servo drive)
• Gas turbines and generator set monitoring (gas turbine cards, power regulation)
• Industrial automation systems (PLC, SCADA fieldbus nodes)
• Heavy industries such as electric power, petroleum, and mining (power supply and control)

Installation and Maintenance Guidelines

Pre-Installation Inspection

1. Confirm that the power voltage, terminal connections, and heat dissipation space meet the specifications.
2. Verify that the protection rating matches the ambient temperature.

Mechanical Fixing

• Secure the module to the cabinet or guide rail using bolts to ensure shock resistance and unobstructed heat dissipation channels.

Electrical Wiring

• Connect the input power, output load, and communication bus in accordance with the wiring diagram.
• Use compliant cables and terminals for high-current circuits.

Parameter Configuration

• Set parameters (such as motor rated power, control mode, and PID parameters) using the configuration software provided by GE or via the fieldbus.

Functional Testing

• After power-on, first perform a no-load operation check to confirm that communication and protection functions are normal before connecting the load.

Regular Maintenance

1. Inspect heat sinks for dust accumulation and check for loose fastening screws every 6 ~ 12 months.
2. Monitor the operating temperature and current to ensure they remain within the rated range.
3. If abnormal alarms occur (overvoltage, overcurrent, communication failure), replace or repair the module promptly.

Spare Parts Management

• It is recommended to keep spare modules of the same model or key electronic components on hand to minimize downtime due to faults.

————————————————————————————————————-
