HIMA Z7138/3330/C8/P2

Overview

Main Specifications

• Model: Z7138/3330/C8/P2
• Compatible I/O Module: Z3330 (16-channel I/O)
• Mounting Method: DIN rail (19 inches)
• Power Supply: 24 V DC (5 V DC optional)
• Communication Interfaces: Modbus RTU, RS-232/RS-485, Ethernet
• Protection Level: IP20 (indoor use)
• Safety Level: Compliant with IEC 61508, supporting SIL 3 certification
• Operating Temperature: -20 °C ~ +55 °C
• Dimensions: 4 U (19 inches)

Product Features

1. High Reliability and Safety: Adopts advanced hardware and software redundancy design to meet the requirements of SIL 3 safety level.
2. Modular Structure: Can be combined with Z3330 I/O modules, F7131 power modules, etc., supporting hot-swapping for easy replacement.
3. Compact Heat Dissipation: Fanless design ensures excellent heat dissipation performance, making it suitable for cabinets with limited space.
4. Multi-Protocol Support: Compatible with industrial communication protocols such as Modbus, RS-485, and Ethernet, facilitating system integration.
5. Easy Maintenance: Provides complete installation manuals and diagnostic functions, supporting remote monitoring and fault location.

Structure and Composition

• Main Control Unit (CPU): Responsible for safety logic operations and monitoring.
• Power Module: 24 V DC main power supply, matched with 5 V DC auxiliary power supply (F7131).
• Communication Module: Provides multiple industrial communication interfaces.
• Redundant Card Slots: Two sets of cards can achieve hot-swappable redundancy to improve system availability.
• Rack and Card Cage: Standard 19-inch DIN rail rack with a height of 4 U, facilitating stacking in cabinets.

Application Fields

• Process control systems in high-risk industries such as petrochemicals, chemicals, natural gas, pharmaceuticals, iron and steel, cement, automobiles, and textiles.
• Automation systems requiring high safety levels in fields such as electric power, energy, and transportation.
• Any DCS/PLC solutions that require SIL 3 level safety protection.

Installation and Maintenance

Installation

Wiring

Commissioning

Maintenance

• Regularly check the power supply status, heat dissipation condition, and card connections.
• In case of failure, redundant cards can be replaced via hot-swapping to minimize downtime.

————————————————————————————————————-
