ABB PM595-4ETH-F 1SAP155500R3379 Central Processor Module

Short Description:

The ABB PM595-4ETH-F (Order No.: 1SAP155500R3379) is a high-performance central processing unit (CPU) module belonging to the ABB AC500 series of programmable logic controllers (PLCs).

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: ABB

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-15359273791

( WhatsApp )Wechat: + 86-15359273791

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

ABB PM595-4ETH-F

1. Product Overview

The ABB PM595-4ETH-F (Order No.: 1SAP155500R3379) is a high-performance central processing unit (CPU) module belonging to the ABB AC500 series of programmable logic controllers (PLCs). Designed exclusively for industrial automation control, this module features powerful processing performance and comprehensive communication interfaces, meeting the control requirements of diverse complex industrial scenarios.

2. Technical Parameters

Parameter Item	Technical Specification
Model	PM595-4ETH-F
Order Number	1SAP155500R3379 / 1SAP155500R0279
Processor	1.3GHz High-performance Processor
Program Memory	16 MB
Data Memory	16 MB
Flash Disk	4 GB
Power Supply Voltage	24 V DC
Power Consumption	Approx. 15W
Cycle Time	0.0006 – 0.001 μs per instruction
Operating Temperature	Wide temperature range (-40℃ to +70℃)
Weight	Approx. 1.05 kg

Communication Interface Configuration

Interface Type	Quantity	Description
Ethernet Interface (RJ45)	2	Supports 2-port switch
Serial Port (COM)	2	Configurable for RS232/RS485
Ethernet Interface (with Switch)	2	Supports protocol download
Coupler Slot	2	For expansion module connection
Memory Card Slot	1	Supports FAT file system

3. Product Features

3.1 High-performance Processing Capability

Equipped with a 1.3GHz high-speed processor, the module delivers fast execution speed with an ultra-low instruction cycle time of 0.0006μs. The 16 MB program memory and 16 MB data memory fully meet the operational demands of large-scale and complex control projects, ensuring stable and efficient system operation.

3.2 Versatile Communication Performance

It supports multiple built-in industrial network protocols, including Ethernet, PROFINET, EtherCAT, and Modbus TCP. The compatible protocol versions are specified as PROFINET V2.8.1.2+, EtherCAT V4.2.23+, and Ethernet V1.2.0.20+.

With excellent scalability, it can switch between various bus protocols (such as Profibus DP and DeviceNet) via FBP bus adapters. The module supports automatic bus protocol identification without manual complex configuration, simplifying on-site deployment and debugging.

3.3 Flexible Expansion Capability

The module supports expansion of up to 10 I/O modules. Equipped with 2 coupler slots, it enables flexible connection of various expansion modules to adapt to diverse functional expansion needs. It also reserves an SD card slot for storage expansion, facilitating convenient program downloading and firmware upgrade operations.

3.4 Reliable Industrial-grade Design

It is equipped with comprehensive status indication functions, including 5 LED indicators for processor status and 10 LED indicators for field bus status, enabling real-time monitoring of system operating conditions.

It adopts battery backup design: the TA521 lithium battery is used for SRAM data and RTC cache backup (TA541 battery for XC version). To avoid severe module damage and enhance equipment stability, the TA543 screw mounting accessory is recommended for installation and protection.

4. Structure and Composition

4.1 Physical Structure

The overall structural configuration of the ABB PM595-4ETH-F processor module is as follows:

10 LED indicators: For field bus status display
5 LED indicators: For processor status display
2 RJ45 interfaces: Standard Ethernet interfaces
2 RJ45 interfaces: Ethernet interfaces with built-in switch
2 Serial ports (COM1/COM2): Configurable RS232/RS485 interfaces
1 Memory card slot: SD card expansion slot
1 Reset button: For system manual reset
Power interface: 5-pin detachable terminal block
2 Coupler slots: For system expansion connection
5 Mounting holes: For standard DIN rail installation

4.2 System Composition

Component	Description
Central Processing Unit	Built-in 1.3GHz processor, responsible for system operation calculation and logic control
Communication Module	Supports ETH3 and ETH4 interface configuration and multi-protocol communication
Battery Unit	TA521/TA541 lithium battery for system data backup
Storage Media	4 GB built-in flash disk + expandable SD card slot
Power Supply Unit	24 V DC detachable 5-pin terminal block interface
Expansion Interface	2 coupler slots + I/O expansion bus

5. Application Fields

Leveraging its high performance, strong compatibility and excellent stability, the PM595-4ETH-F PLC module is widely applied in various industrial automation scenarios, covering the following fields:

Application Field	Specific Applications
Renewable Energy	Wind turbines, solar trackers
Power and Energy Industry	High-voltage switchgear production, power grid monitoring and control
Transportation	Large marine vessels, tunnel automation systems, traffic control systems
Mechanical Manufacturing	Packaging machinery, printing presses, industrial robots
Smart Manufacturing	Semiconductor manufacturing equipment, smart factory systems
Other Industrial Scenarios	Industrial 5G networks, industrial edge computing applications

————————————————————————————————————-
