PROSOFT MVI56-MBP

The ProSoft MVI56-MBP is a dual‑port Modbus Plus communication module designed specifically for Rockwell Automation’s ControlLogix® PLC platform. It plays a critical role in industrial automation networks by connecting the ControlLogix system with Modbus Plus devices, supporting both Master and Slave communication modes.

1. Overview

• Model: MVI56-MBP (Modbus Plus Dual‑Port)
• Type: Fieldbus communication module
• Key Function: Enables efficient data exchange between the ControlLogix PLC and Modbus Plus networks, supporting both Master and Slave operations.

2. Technical Specifications

• Backplane Current Draw: 800 mA @ 5V DC
• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 5% to 95% (non-condensing)
• Serial Ports: Two independently configurable ports (RS-232, RS-422, RS-485)
• Baud Rate: 110 to 115,200 baud
• Parity: None, Even, Odd
• Data Bits: 7 or 8 bits
• Stop Bits: 1 or 2 bits

3. Product Features

• Dual‑Port Design: Two independently configurable serial ports for maximum flexibility in connecting various devices.
• High Reliability: Supports redundant communication to ensure secure transmission of critical data in industrial environments.
• Easy Integration: Compatible with the 1756 ControlLogix backplane and can be directly inserted into any I/O slot.
• Powerful Software Support: Configured via ProSoft Configuration Builder (PCB) software, with LED status indicators and menu-driven diagnostics for easy troubleshooting.

4. Structure and Components

• Hardware: Single-slot design that fits into Rockwell PLC racks, with built‑in power management and isolation circuits.
• Interfaces: Provides standard RS-232 / RS-485 / RS-422 connections for linking Modbus Plus field devices.
• Internal Architecture: Features an independent communication processor and dedicated register mapping area for efficient data buffering and processing.

5. Application Areas

• Industrial Automation: Connects PLCs with sensors and actuators in factory automation systems.
• Process Control: Monitors and controls process variables in continuous process industries such as chemical, oil and gas, and pharmaceuticals.
• Energy Management: Used for data acquisition in power generation, wind energy, and other energy-related applications.
• Building Management: Enables centralized control in Building Automation Systems (BMS).

6. Installation and Maintenance

Hardware Installation

Configuration Steps

1. Port Settings: Use PCB software to configure communication parameters for each port, such as baud rate, parity, and protocol type.
2. Data Mapping: Define register address mapping between the PLC and external devices.
3. Download Configuration: Download the configuration file to the PLC and restart the module for changes to take effect.

Maintenance
